ND22 8" Round Trim Haze Reflector and Flange for ND22-20, ND22-30 and ND22-50
Available in stock (200)
About this item
About this item
- Unified Haze High-Output Design: The matching 8" haze reflector and flange create cohesive, sophisticated appearance with superior glare control for 1,850 to 4,700 lumens of output, perfect for commercial spaces requiring both high illumination and visual comfort.
- Maximum Glare Reduction at Scale: Engineered to minimize harsh reflections even at high output levels, this larger trim excels in office workspaces, healthcare facilities, and educational environments where occupant comfort and substantial illumination are both essential.
- Expanded Aperture Performance: The 8" round opening accommodates higher lumen packages and larger beam spreads while maintaining the glare control benefits of the unified haze finish, ideal for spaces with higher ceilings or broader coverage requirements.
- High-Output Module Integration: Designed for ND22-20, ND22-30, and ND22-50 modules, this trim delivers 1,850 to 4,700 lumens with field-adjustable color temperature (2700K-5000K), three brightness levels, and adjustable beam angle for complete customization.
- Field-Adaptable Installation: RAB's twist-lock mechanism enables quick, tool-free trim changes on site, allowing contractors to respond to aesthetic requirements and visual comfort needs in high-output applications without project delays or costly reorders.
We process payments securely and do not store credit card information.
Description
Description
Premium 8" Unified Haze Round Trim for High-Output Glare Control
The RAB Lighting ND22T-8RHZ features a refined haze reflector with matching flange in an expansive 8" round aperture, specifically designed for ND22-20, ND22-30, and ND22-50 modules. This larger trim delivers exceptional glare reduction while providing 1,850 to 4,700 lumens of adjustable illumination, making it ideal for commercial spaces requiring high output with superior visual comfort. The monochromatic haze finish creates a cohesive, sophisticated appearance that complements contemporary interiors. RAB's commercial-grade engineering ensures consistent high-output performance across offices, healthcare facilities, and hospitality environments where visual comfort at scale is paramount.
Unified Haze Aesthetic with High-Output Modular Performance
Part of RAB's innovative ND22 platform, the ND22T-8RHZ (SKU: ND22T-8RHZ) combines superior glare control with high-output field-adjustable flexibility. The matching haze reflector and flange in an 8" format create a seamless, refined appearance while the twist-lock mechanism enables effortless installation and on-site changes. Compatible with ND22-20, ND22-30, and ND22-50 modules, this trim provides substantial customizable illumination with adjustable color temperature, brightness, and beam angle. This RAB Lighting solution delivers visual comfort without compromising on output or flexibility.
Engineered for High-Output Visual Comfort and Flexibility
- 8" round haze reflector and flange for unified high-output glare control
- Compatible with ND22-20 (1,850lm), ND22-30 (2,800lm), and ND22-50 (4,700lm) modules
- Adjustable 25° to 45° (20/30W) or 30° to 50° (50W) beam angle
- Larger aperture for expanded beam spreads and high-output applications
- Supports 5 selectable CCTs (2700K-5000K) and 3 brightness levels
Specifications
Specifications
Dimensions
Style & Materials
Characteristics & Features
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the difference between Lumens and Watts?
What is the difference between Lumens and Watts?
Watts measure the amount of electrical energy a fixture consumes, while lumens measure the actual brightness (the amount of visible light produced). In the LED era, wattage is no longer a reliable indicator of brightness. When replacing old fixtures or comparing new ones, always look at the lumen output to determine how bright the light will be.
What is Color Rendering Index (CRI) and why does it matter?
What is Color Rendering Index (CRI) and why does it matter?
CRI is a scale from 0 to 100 that measures how accurately a light source reveals the true colors of objects compared to natural sunlight. A higher CRI (90+) ensures colors look vibrant and accurate, which is critical for retail displays, kitchen countertops, and bathroom vanities. A lower CRI (under 80) can make colors look washed out or dull, regardless of the color temperature.
How do I know if my light fixture is dimmable?
How do I know if my light fixture is dimmable?
For traditional incandescent fixtures, dimmability depended purely on the bulb. For modern LED lighting, dimmability depends on the internal LED driver or the specific LED bulb used. A fixture is only dimmable if its driver is explicitly rated for it. Furthermore, the fixture must be paired with a compatible dimmer switch (such as a standard TRIAC/Phase-cut dimmer or a 0-10V commercial dimmer) to prevent flickering and buzzing.
What does "Integrated LED" mean compared to a standard fixture?
What does "Integrated LED" mean compared to a standard fixture?
An integrated LED fixture has the LED diodes and driver built directly into the housing, meaning there are no traditional bulbs to screw in or replace. This allows for sleeker, lower-profile designs and better heat dissipation. However, if an integrated fixture fails after its warranty period, you typically have to replace the entire unit or the internal driver, rather than just swapping out a bulb.
What does the "L70" lifespan rating mean on LED fixtures?
What does the "L70" lifespan rating mean on LED fixtures?
Unlike traditional bulbs that simply burn out and go dark, LEDs gradually lose their brightness over time (lumen depreciation). The L70 rating indicates the number of operating hours it takes for the LED fixture to degrade to 70% of its original brightness. For example, a fixture rated for "50,000 hours L70" will still work after 50,000 hours, but it will be noticeably dimmer than when it was first installed.
