ND22 6" Round Trim Black Reflector and Flange for ND22-12
Available in stock (200)
About this item
About this item
- Dramatic Black Aesthetic: The black reflector and flange create sophisticated visual depth and minimize ceiling contrast, perfect for upscale retail, hospitality, and contemporary commercial spaces where fixtures become design elements.
- ND22-12 Module Integration: Precisely engineered for the 12W ND22 module, this trim delivers 1,000 lumens of adjustable output with field-selectable color temperature (2700K-5000K) and three brightness levels for ultimate customization.
- Classic Round Aperture: The 6" round opening provides timeless architectural appeal that complements both traditional and modern ceiling designs across diverse commercial and hospitality applications.
- Adjustable Beam Control: Works with ND22's rotating lens assembly to adjust beam angle from 25° to 45° on site, allowing contractors to fine-tune light distribution without changing fixtures or modules.
- RAB Modular Advantage: Part of RAB's innovative ND22 platform, this trim reduces SKU sprawl and enables last-minute aesthetic changes through simple twist-lock swaps, streamlining specification and installation processes.
We process payments securely and do not store credit card information.
Description
Description
Sleek Black Round Trim for Architectural Precision
The RAB Lighting ND22T-6RB combines a sophisticated black reflector with matching flange, specifically engineered for the ND22-12 module. This 6" round trim delivers dramatic visual impact while maintaining RAB's commercial-grade performance standards. The black finish minimizes ceiling contrast and creates a refined, upscale aesthetic perfect for boutique retail, galleries, restaurants, and contemporary office spaces where lighting becomes part of the architectural statement.
Modular Versatility for Design-Forward Projects
As part of the ND22 modular ecosystem, the ND22T-6RB (SKU: ND22T-6RB) offers specifiers and designers unmatched flexibility. The twist-lock mechanism allows for quick trim changes on site, while compatibility with the 12W ND22 module provides 1,000 lumens of field-adjustable illumination. This RAB Lighting solution reduces SKU complexity and simplifies logistics without compromising on aesthetic options or performance quality.
Premium Features for Professional Applications
- 6" round black reflector and flange for sophisticated aesthetics
- Compatible with ND22-12 module (1,000lm output)
- Tool-free twist-lock installation system
- Adjustable 25° to 45° beam angle with rotating lens assembly
- Supports 5 selectable CCTs (2700K-5000K) and 3 brightness levels
Specifications
Specifications
Dimensions
Style & Materials
Characteristics & Features
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the difference between Lumens and Watts?
What is the difference between Lumens and Watts?
Watts measure the amount of electrical energy a fixture consumes, while lumens measure the actual brightness (the amount of visible light produced). In the LED era, wattage is no longer a reliable indicator of brightness. When replacing old fixtures or comparing new ones, always look at the lumen output to determine how bright the light will be.
What is Color Rendering Index (CRI) and why does it matter?
What is Color Rendering Index (CRI) and why does it matter?
CRI is a scale from 0 to 100 that measures how accurately a light source reveals the true colors of objects compared to natural sunlight. A higher CRI (90+) ensures colors look vibrant and accurate, which is critical for retail displays, kitchen countertops, and bathroom vanities. A lower CRI (under 80) can make colors look washed out or dull, regardless of the color temperature.
How do I know if my light fixture is dimmable?
How do I know if my light fixture is dimmable?
For traditional incandescent fixtures, dimmability depended purely on the bulb. For modern LED lighting, dimmability depends on the internal LED driver or the specific LED bulb used. A fixture is only dimmable if its driver is explicitly rated for it. Furthermore, the fixture must be paired with a compatible dimmer switch (such as a standard TRIAC/Phase-cut dimmer or a 0-10V commercial dimmer) to prevent flickering and buzzing.
What does "Integrated LED" mean compared to a standard fixture?
What does "Integrated LED" mean compared to a standard fixture?
An integrated LED fixture has the LED diodes and driver built directly into the housing, meaning there are no traditional bulbs to screw in or replace. This allows for sleeker, lower-profile designs and better heat dissipation. However, if an integrated fixture fails after its warranty period, you typically have to replace the entire unit or the internal driver, rather than just swapping out a bulb.
What does the "L70" lifespan rating mean on LED fixtures?
What does the "L70" lifespan rating mean on LED fixtures?
Unlike traditional bulbs that simply burn out and go dark, LEDs gradually lose their brightness over time (lumen depreciation). The L70 rating indicates the number of operating hours it takes for the LED fixture to degrade to 70% of its original brightness. For example, a fixture rated for "50,000 hours L70" will still work after 50,000 hours, but it will be noticeably dimmer than when it was first installed.
