Sylvania UltraLED Wraparound Light — 44W Selectable Configuration

The Sylvania 62178 UltraLED Wraparound Light offers a versatile lighting solution with selectable wattage and color temperature options. This fixture provides up to 5700 lumens with a selectable wattage of 22, 28, 34, or 44 watts and operates on 120-277V. It is ideal for retail, manufacturing, warehouse, office, and educational environments, offering increased energy savings and design flexibility. The fixture is DLC Premium certified, ensuring high performance and rebate eligibility.

Key Features

• Diffuse Acrylic Lens: Provides smooth, even illumination without LED pixilation.
• Selectable CCT: Choose between 3500K, 4000K, and 5000K for optimal lighting conditions.
• Lumen Selectability: Offers multiple lumen outputs for tailored lighting needs.
• Integrated Sensor Options: Compatible with motion and daylight sensors for enhanced control.
• High Efficacy: Achieves up to 130 lumens per watt for energy efficiency.
• Long Lifespan: Rated for 100,000 hours (L70), reducing maintenance costs.
• Power Factor: Greater than 90% for efficient power usage.
• Dimmable: 0-10V dimming capability down to 10% for adjustable brightness.
• UL Damp Rated: Suitable for damp locations, expanding installation possibilities.
• Optional Battery Backup: Provides 1000 lumens for 90 minutes during power outages.

Typical Applications

• Retail Environments
• Manufacturing Facilities
• Warehouses
• Offices
• Educational Institutions

Performance & Light Output

This fixture delivers up to 5700 lumens with an efficacy of 130 LPW. It features a CRI greater than 80, ensuring accurate color rendering. The fixture is designed for a long lifespan of 100,000 hours (L70).

Electrical & Controls

Operates on a universal voltage range of 120-277V with a power factor greater than 90%. It supports 0-10V dimming down to 10% and includes a 12V auxiliary output. Optional motion and daylight sensors enhance control capabilities.

Construction & Durability

The fixture features a durable white finish with a diffuse acrylic lens. It is UL damp rated, suitable for various environments, and operates within a temperature range of -4°F to +104°F.

Installation & Mounting

Can be surface mounted or suspended using the included V-hook. An optional joiner bracket is available for end-to-end mounting.

What's Included

• Wraparound Light Fixture
• V-hook for Mounting
