Sylvania RT Dual Selectable Open Deep Regressed LED Downlight — 4/6/8/10 in / Selectable CCT / 120-277V / White

The Sylvania RT Dual Selectable is a round open deep regressed LED canless downlight family from the LEDVANCE Performance Class, available in 4 in, 6 in, 8 in, and 10 in sizes with two lumen packages per 6 in and 8 in. All models feature field-selectable 3-step output and CCT (2700K–5000K), an 85° beam angle, uniform glare-free illumination, CRI >90, R9 >50, IC rated, airtight per ASTM E283-04, IP44, wet rated, emergency battery backup ready, and both Phase-Cut and 0-10V dimming (100–10%) at 120-277V. ENERGY STAR certified. Title 24 compliant. TAA compliant. L70: 100,000 hours. 5-year warranty.

Series Overview

• Sylvania 67685 (4 in, 120-277V): 6/8/10W | 600/800/1000 lm | 100 LPW | Catalog: RT4S1000UNVD9SC3WH | 120-347V: see Sylvania 67691
• Sylvania 67686 (6 in, 120-277V — 900 lm): 5/7/9W | 500/700/900 lm | 100 LPW | Catalog: RT6S900UNVD9SC3WH | 120-347V: see Sylvania 67692
• Sylvania 67687 (6 in, 120-277V — 2500 lm): 10/17/21W | 1000/1800/2500 lm | 119 LPW | Catalog: RT6S2500UNVD9SC3WH | 120-347V: see Sylvania 67692
• Sylvania 67688 (8 in, 120-277V — 1500 lm): 9/12/15W | 900/1200/1500 lm | 100 LPW | Catalog: RT8S1500UNVD9SC3WH | 120-347V: see Sylvania 67693
• Sylvania 67689 (8 in, 120-277V — 3500 lm): 16/24/30W | 1800/2700/3500 lm | 117 LPW | Catalog: RT8S3500UNVD9SC3WH | 120-347V: see Sylvania 67693
• Sylvania 67690 (10 in, 120-277V): 24/30/37W | 2800/3500/4500 lm | 122 LPW | Catalog: RT10S4500UNVD9SC3WH | Note: 120-347V not available for 10 in

Key Features (All Models)

• Construction: White aluminum housing | Open deep regressed trim | Max ceiling thickness: 1.97 in (50mm) | 16 in input wires
• Beam Angle: 85° | Uniform, glare-free illumination
• Field-Selectable CCT: 2700K / 3000K / 3500K / 4000K / 5000K
• CRI: >90 | R9 >50
• Input Voltage: 120-277V | 120-347V available for 4/6/8 in sizes only
• Dimming: Phase-Cut (TRIAC/ELV) AND 0-10V | 100–10% | Both methods in same product
• Power Factor: >0.9 @120V | >0.7 @277V or 347V
• THD: ≤20% | Surge Protection: 2.5 kV
• IC Rating: Yes — IC rated for direct contact with ceiling insulation
• Air Tight: Yes — certified per ASTM E283-04
• Environment: Wet rated | IP44 | Op temp: -4°F to 104°F | With battery: 32°F to 104°F
• Emergency Battery: Backup ready — field-installable kit provides up to 2 hours illumination
• Lifespan: 100,000 hours L70 @ 77°F/25°C | Warranty: 5-year / NLB Trusted Warranty Program
• Certifications: ENERGY STAR Certified | Title 24 Compliant | TAA Compliant | UL Listed (US & Canada) | cUL | Wet | IC | IP44 | FCC | RoHS | ASTM E283-04

Construction & Aesthetics

Housing: White aluminum | Trim: Open deep regressed | Max ceiling thickness: 1.97 in (50mm) | Input wires: 16 in. The deep recess minimizes glare and keeps the ceiling face uncluttered. Optional field-installable color trim rings (dark bronze, satin nickel, black, or white flange) allow finish customization per size without changing the fixture.

Light Output & Performance

The RT Dual Selectable family delivers from 500 lm (6 in / 5W) up to 4,500 lm (10 in / 37W / 122 LPW) with CRI >90 and R9 >50. The 85° beam angle provides uniform, glare-free illumination across all sizes. Field-selectable 3-step output and 5 CCT options per model allow a single SKU to cover multiple applications. L70 rated lifespan is 100,000 hours across the family.

Electrical & Installation

All RT Dual Selectable models operate at 120-277V with both Phase-Cut (TRIAC/ELV) and 0-10V dimming from 100% to 10% in the same product. PF >0.9 @120V; THD ≤20%; surge protection 2.5 kV. Max ceiling thickness: 1.97 in (50mm). 16 in input wires. IC rated and airtight per ASTM E283-04. Emergency battery backup field-installable. For 120-347V operation, see Sylvania 67691 (4 in), Sylvania 67692 (6 in), and Sylvania 67693 (8 in). Note: 120-347V is not available for the 10 in size.

Compatible Accessories by Size (Sold Separately)

• 4 in Trim Rings: Sylvania 67426 RT4TRIMSSWH (white) | 65710 RT4TRIM5ADKBZ (dark bronze) | 65711 RT4TRIM5ASN (satin nickel) | 65712 RT4TRIM5ABLK (black) | Rough-In: 63883 LEDRT4FRAME
• 6 in Trim Rings: Sylvania 67427 RT6TRIMSSWH (white) | 65713 RT6TRIM5ADKBZ (dark bronze) | 65714 RT6TRIM5ASN (satin nickel) | 65715 RT6TRIM5ABLK (black) | Goof Ring: 62788 RT685ATRIMEXT | Rough-In: 71708 LEDRT6HOFRAME
• 8 in Trim Rings: Sylvania 67428 RT8TRIMSSWH (white) | 65716 RT8TRIM5ADKBZ (dark bronze) | 65717 RT8TRIM5ASN (satin nickel) | 65718 RT8TRIM5ABLK (black) | Goof Rings: 62788 RT685ATRIMEXT | 62789 RT8105ATRIMEXT | Rough-In: 71709 LEDRT8FRAME
• 10 in Trim Rings: Sylvania 67429 RT10TRIMSSWH (white) | 65719 RT10TRIM5ADKBZ (dark bronze) | 65720 RT10TRIM5ASN (satin nickel) | 65721 RT10TRIM5ABLK (black) | Goof Rings: 62789 RT8105ATRIMEXT | 62790 RT8125ATRIMEXT | 62791 RT10125ATRIMEXT
• Emergency Battery Back-Up (all sizes): Sylvania 62367 EMBB2A8WUNVDC (100-277V, 90 min) | Sylvania 62368 EMBB2A8WUNHDC (100-347V, 90 min)

Typical Applications

• Commercial offices, schools, and big box retail
• Hotels, shops, and hospitality environments
• Public and commercial buildings
• Residential interiors and great rooms
• New installations and retrofit of existing installations
• Wet and damp locations
• Emergency lighting applications
