LEDVANCE Sylvania Dual Selectable 2FT Linear LED High Bay — 105–300W Selectable — 4000K/5000K — 120–277V / 277–480V — White
Regular price
$163.26
Sale price
Regular price
$0.00
Shipping calculated at checkout.
Available in stock (302)
Arrives by
Must be ordered in quantities of .
About this item
About this item
- Selectable Output: Choose from 3 wattage configurations — 105/135/165W, 175/195/220W, or 255/275/300W — delivering up to 41,100 lumens at up to 144 lm/W. No rewiring required.
- Selectable CCT: Field-select 4000K or 5000K at the fixture — one SKU covers neutral white and cool white for any facility environment.
- Compact 2FT Form Factor: Designed for lower mounting heights and tighter bay spacing — ideal for mezzanines, loading docks, and facilities where standard 4FT fixtures are oversized. Available in 120–277V and 277–480V.
- DLC 5.1 Premium: Qualifies for the highest tier of utility rebate programs in most U.S. markets.
- LEDVANCE LINK™ Bluetooth® Mesh Ready: Pre-wired sensor base accepts LEDVANCE LINK motion and daylight sensors for occupancy-based automation. 0–10V dimming standard.
Payment & Security
Payment methods
We process payments securely and do not store credit card information.
Description
Description
LEDVANCE Sylvania Dual Selectable Linear High Bay 5A — 105–300W Selectable | 120–480V | White
The LEDVANCE Sylvania Dual Selectable Linear High Bay 5A covers four configurations across three wattage tiers and two voltage ranges, giving specifiers and contractors a single family to right-size output for ceiling heights from 15 to 40 ft. Field-selectable wattage and CCT (4000K / 5000K) are adjustable on site without re-ordering. Up to 41,100 lumens at up to 144 lm/W peak efficacy. Available in 120–277V (Items 62875, 62876, 62877) and 277–480V (Item 66202). DLC 5.1 Premium listed across all models. Replaces 4- to 8-lamp 54T5HO fluorescent or up to 1000W HID.
Key Features
- Selectable Wattage: 105/135/165W (62875) · 175/195/220W (62876) · 255/275/300W (62877, 66202) — field-adjustable on site
- Selectable CCT: 4000K / 5000K — tunable without re-ordering
- Max Lumen Output: 41,100 lm @ 300W
- Peak Efficacy: Up to 144 lm/W
- CRI: >80
- Voltage: 120–277V (Items 62875, 62876, 62877) or 277–480V (Item 66202)
- Dimming: 0–10V
- Power Factor: >0.9 · THD: <20%
- Surge Protection: 6kV
- Location Rating: Damp Location
- Operating Temperature: -22°F to +122°F (-30°C to +50°C)
- Rated Life: 100,000 hours (L70)
- Warranty: 5 years (NLB Trusted Warranty Program)
- Controls Ready: Pre-wired sensor base accepts field-installable sensors or LEDVANCE LINK™ Bluetooth® Mesh modules (sold separately)
- Finish: White
Performance & Light Output
| Item # | Wattage | Lumens @4000K | Efficacy | Fluorescent Equal | HID Equal | Voltage |
|---|---|---|---|---|---|---|
| 62875 | 105W | 14,600 lm | 139 lm/W | 4-lamp 54T5HO | ~175W HID | 120–277V |
| 62875 | 135W | 18,600 lm | 138 lm/W | 4-lamp 54T5HO | ~200W HID | 120–277V |
| 62875 | 165W | 22,100 lm | 134 lm/W | 4-lamp 54T5HO | ~250W HID | 120–277V |
| 62876 | 175W | 24,400 lm | 139 lm/W | 4-lamp 54T5HO | ~320W HID | 120–277V |
| 62876 | 195W | 26,900 lm | 138 lm/W | 6-lamp 54T5HO | ~370W HID | 120–277V |
| 62876 | 220W | 29,000 lm | 132 lm/W | 6-lamp 54T5HO | ~400W HID | 120–277V |
| 62877 | 255W | 36,700 lm | 144 lm/W | 8-lamp 54T5HO | ~600W HID | 120–277V |
| 62877 | 275W | 38,700 lm | 141 lm/W | 8-lamp 54T5HO | ~750W HID | 120–277V |
| 62877 / 66202 | 300W | 41,100 lm | 137 lm/W | 8-lamp 54T5HO | ~1000W HID | 120–277V / 277–480V |
CRI >80 across all wattage and CCT settings. Rated life 100,000 hours (L70) per IES TM-21.
Smart & Control Features
All 5A linear fixtures include a pre-wired screw-in sensor base — no wiring required. Compatible accessories (sold separately):
- Microwave Motion/Daylight Sensor — Item 65622 (IP65, max 49 ft mounting height)
- PIR DC Motion/Daylight Sensor — Item 62664 (IP65, max 30 ft mounting height)
- Remote Control (required to change default sensor settings) — Item 65623
- LEDVANCE LINK™ Bluetooth® Mesh — BLE controller (Item 62630) or BLE sensor+controller (Item 62634)
- 5-Button Wall Controller — Item 62636
Electrical
Constant current LED driver. 120–277V (Items 62875, 62876, 62877) or 277–480V (Item 66202), 50/60Hz. Power factor >0.9. THD <20%. Surge protection: 6kV. 0–10V dimming standard. RoHS compliant.
Construction
White steel housing with polycarbonate lens. Suitable for damp locations. Ambient operating range: -22°F to +122°F (-30°C to +50°C).
- 165W body (62875): 24.0" L × 11.8" W × 1.6" H · 5.47 lb
- 220W & 300W body (62876, 62877, 66202): 24.0" L × 14.2" W × 1.6" H
Installation & Mounting
Ships with V-hooks and 3-foot mounting chains. Optional accessories (sold separately):
- Surface Mount Bracket — Item 62904
- Pendant Mount Bracket — Item 62905
- Wire Guard (165W) — Item 62906 · Wire Guard (220W & 300W) — Item 62907
- Chain Mount (5 ft) — Item 60573 (2 per SKU)
- Cable Mount (5 ft) — Item 60574 (2 per SKU)
Certifications & Rebates
-
Ordering Abbreviations:
- Item 62875 — LNHIBA5A/S165UNVD8SC14/12/WH (105/135/165W, 120–277V)
- Item 62876 — LNHIBA5A/S220UNVD8SC14/12/WH (175/195/220W, 120–277V)
- Item 62877 — LNHIBA5A/S300UNVD8SC14/12/WH (255/275/300W, 120–277V)
- Item 66202 — LNHIBA5A/S300HUVD8SC14/12/WH (255/275/300W, 277–480V)
- DLC 5.1 Premium Listed — qualifies for utility rebate programs in most U.S. markets. Verify at designlights.org.
- cULus Listed — Damp Location rated
- RoHS Compliant
- 5-Year Warranty — NLB Trusted Warranty Program
Typical Applications
- Warehouses and distribution centers — replaces 4- to 8-lamp 54T5HO or up to 1000W HID for up to 73% energy savings
- Manufacturing and assembly facilities — selectable CCT and wattage right-size output to task and ceiling height
- Big-box retail and large commercial spaces
- Gymnasiums and recreational facilities
- Loading docks and industrial storage
- High-voltage 480V facilities (Item 66202) — eliminates step-down transformers
What’s Included
- LEDVANCE Sylvania Dual Selectable Linear High Bay 5A (item per selection)
- V-hooks
- 3-foot mounting chains
Specifications
Specifications
Documents
Item Details
MPN
62875
MPN
62876
MPN
66202
MPN
62877
Brand
Sylvania
Family
Linear High Bay 5A
UPC
046135628757
Frequently Asked Questions
How do I choose the right wattage tier and voltage for my application?
How do I choose the right wattage tier and voltage for my application?
Select the tier based on your mounting height and target footcandles, then select voltage based on your facility's distribution. Item 62875 (105/135/165W, 120–277V): best for ceiling heights of 15–25 ft, replacing up to 4-lamp 54T5HO or 250W HID. Item 62876 (175/195/220W, 120–277V): best for 20–30 ft, replacing up to 6-lamp 54T5HO or 400W HID. Item 62877 (255/275/300W, 120–277V): best for 25–40 ft, replacing up to 8-lamp 54T5HO or 1000W HID. Item 66202 (255/275/300W, 277–480V): same output as 62877 but for 480V three-phase facilities. Within each tier, wattage is field-selectable on site without rewiring.
What is the difference between Item 62877 and Item 66202?
What is the difference between Item 62877 and Item 66202?
Items 62877 and 66202 are identical in wattage (255/275/300W), lumen output (36,700–41,100 lm), and efficacy (up to 144 lm/W). The only difference is input voltage: the 62877 operates on 120–277V (standard low-voltage distribution), while the 66202 operates on 277–480V (high-voltage three-phase distribution). Choose the 66202 for facilities with 480V three-phase power to avoid the need for step-down transformers.
Can I adjust wattage and CCT after the fixture is installed?
Can I adjust wattage and CCT after the fixture is installed?
Yes. Both wattage and CCT are field-selectable on the fixture itself — no tools, no rewiring, and no accessories required. Wattage is adjusted via a built-in selector switch (positions vary by model). CCT is adjusted via a separate switch: 4000K (neutral white) or 5000K (cool white). Both adjustments can be made after installation, allowing contractors and facility managers to fine-tune output without ordering a different fixture.
Are all 5A linear models compatible with motion/daylight sensors and wireless controls?
Are all 5A linear models compatible with motion/daylight sensors and wireless controls?
Yes. All four 5A models (Items 62875, 62876, 62877, 66202) ship with a pre-wired sensor base — no wiring required. Compatible sensors: Item 65622 (Microwave DC, IP65, max 49 ft) and Item 62664 (PIR DC, IP65, max 30 ft). Remote control Item 65623 is required to change default sensor settings. Also compatible with LEDVANCE LINK™ Bluetooth® Mesh components for wireless group control. Default sensor settings: 100% detection area, 10-minute hold time, 50 Lux daylight threshold, 80-minute stand-by period, 30% stand-by dimming.
Are all 5A linear models DLC Premium listed and eligible for utility rebates?
Are all 5A linear models DLC Premium listed and eligible for utility rebates?
Yes. All four 5A models are DLC 5.1 Premium listed, qualifying for the highest rebate tier from DLC Member Utilities. To confirm your utility’s specific incentive or look up ordering abbreviations, visit designlights.org. Ordering abbreviations: Item 62875 — LNHIBA5A/S165UNVD8SC14/12/WH · Item 62876 — LNHIBA5A/S220UNVD8SC14/12/WH · Item 62877 — LNHIBA5A/S300UNVD8SC14/12/WH · Item 66202 — LNHIBA5A/S300HUVD8SC14/12/WH.
