24 Inch LED T8 Sign Tube, 9 Watts, 1300 Lumens, 40K|50K|65K, 360°, R17D Base

Vendor: SATCO|NUVO

SKU: S16431

$21.50
$21.50 $0.00
Shipping calculated at checkout.
Size: 24"

Available in stock (1253)

Must be ordered in quantities of .

About this item
  • Energy Efficient: 9W LED replaces 40W incandescent
  • Base Type: R17D Recessed Double Contact
  • Selectable CCT: 4000K, 5000K, 6500K
  • Installation: Type B Ballast Bypass
  • Enclosed Fixture Rated: Suitable for enclosed fixtures
View More Details
Payment & Security
  • Ach Direct Debit
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • USDC
  • Visa

We process payments securely and do not store credit card information.

Description

Satco 24 Inch T8 LED Sign Tube 9W / Selectable CCT

The Satco S16431 T8 LED bulb features a R17D Recessed Double Contact base and operates at 9 watts, replacing traditional 40W incandescent bulbs. This bulb offers selectable color temperatures of 4000K, 5000K, and 6500K, making it ideal for various lighting environments.

Key Features

  • Base Type: R17D Recessed Double Contact
  • Bulb Shape: T8
  • Wattage Equivalency: 40W incandescent
  • Enclosed Fixture Rated: Yes
  • Certifications: cRUus, cULus, RoHS Compliant
  • Voltage: 120-277V
  • Beam Angle: 360 degrees
  • Surge Protection: Built-in 1KV
  • Operating Temperature: -20C to +45C
  • Power Factor: 0.9
  • CRI: 80+
  • Lifespan: 50,000 hours

Construction & Aesthetics

Constructed with durable polycarbonate material, this T8 bulb features a frosted lens for even light distribution. It measures 21.81 inches in length and 1.15 inches in diameter.

Electrical & Installation

This bulb operates on 120-277V and requires a Type B ballast bypass installation. It is non-dimmable and includes built-in surge protection.

Light Output & Performance

Delivering up to 1300 lumens with a 360-degree beam angle, this LED bulb provides consistent and high-quality light output with a CRI of 80+.

Typical Applications

  • Commercial Signage
  • Office Lighting
  • Retail Displays
  • Warehouse Lighting
  • Industrial Facilities

Specifications

Dimensions

Length/Depth
21.81 in
Width/Diameter
1.13 in
Weight
0.33 lb

Documents

Style & Materials

Finish
White
Material
Plastic
Style
Wedge
Shape
Tubular
Glass
Frost

Characteristics & Features

Lamp Source
LED
Base Type
R17d
Bulb Included
No
Integrated LED
Yes
Bulb
T8
Lamp Color
4000K, 5000K, 6500K, Selectable CCT
Color Rendering
80 CRI
Delivered Lumens
1300
Beam Angle
360.00
Enclosed Rated
Yes

Electrical Information

Voltage
120-277V
Total Wattage
9W
Bulb Wattage
9W

Item Details

MPN
S16431
Brand
SATCO|NUVO
Catalog Number
9T8/LED/HO-SIGN/24-3CCT/BP/SE
UPC
045923164316

Warranty & Certifications

Product Warranty
5 Year Limited - T8 LED Bulbs
Lamp Life
50000 hours
Product Rating
Damp
Safety Listing
cRUus, cULus

Shipping & Returns

Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.

Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.

See Full Shipping Policy | See Full Return Policy

Frequently Asked Questions

What base type does the Satco S16431 LED bulb use?
The Satco S16431 LED bulb uses an R17D Recessed Double Contact base.

Is the Satco S16431 LED bulb dimmable?
No, the Satco S16431 LED bulb is non-dimmable.

Can the Satco S16431 LED bulb be used in enclosed fixtures?
Yes, the Satco S16431 LED bulb is rated for use in enclosed fixtures.

What installation type is required for the Satco S16431 LED bulb?
The Satco S16431 LED bulb requires a Type B ballast bypass installation.

What color temperatures are available for the Satco S16431 LED bulb?
The Satco S16431 LED bulb offers selectable color temperatures of 4000K, 5000K, and 6500K.
