RAB X34XLW Ultra-Economy Field-Adjustable Floodlight — 130W, Selectable CCT & Power, Slipfitter Mount, Photocell, 120-277V, White

The RAB X34XLW is a high-output, extra-large LED flood light in a clean white finish, engineered to provide massive illumination with field-adjustable versatility. This powerful fixture produces up to 20,065 lumens and gives installers complete on-site control with selectable wattage (130W, 110W, 95W) and tunable color temperatures (3000K, 4000K, 5000K). It utilizes a wide 7H x 7V NEMA beam spread, making it an ideal solution for lighting up building perimeters, large landscapes, and expansive parking areas. Operating on a 120-277V driver, the X34XLW includes 0-10V dimming and an integrated, selectable On/Off photocell for automated dusk-to-dawn energy savings. Constructed from rugged precision die-cast aluminum with a tempered glass lens, the IP65-rated X34XLW is built to endure harsh outdoor environments while delivering a 100,000-hour rated lifespan.

Key Features

• Wattage: Field adjustable to 130W, 110W, or 95W (defaults to 130W).
• Selectable CCT: Tunable white 3000K, 4000K, and 5000K (defaults to 4000K).
• Delivered Lumens: Maximum of 20,065 lumens at 130W (4000K).
• Efficacy: Performance levels up to 162.5 Lumens Per Watt (LPW).
• Voltage: 120-277V AC @ 50/60Hz.
• Photocell: Integrated 120-277V selectable On/Off photocell included.
• Environmental Ratings: IP65 rated, suitable for wet locations and mounting within 4ft of the ground.
• Compliance & Certifications: RoHS Compliant, DLC Premium Listed (Product ID: S-2HQ7D4).
• Warranty: 5-Year limited warranty.

Typical Applications

• Large building perimeters and white-themed architectural facades
• Expansive parking lots and auto dealerships
• Industrial yards and wide outdoor storage areas
• General high-output exterior security lighting

Performance & Light Output

The X34XLW provides exceptionally bright and uniform light with a maximum output of 20,065 lumens. The wide 7H x 7V beam spread ensures broad coverage for large areas. With its long-life LEDs rated for 100,000 hours, maintenance costs are significantly reduced over the fixture's long operational life.

Electrical & Controls

This large fixture features a constant current driver and 2kV surge protection to ensure stable operation on 120-277V systems. The integrated photocell provides immediate energy savings with dusk-to-dawn functionality, and the fixture includes wiring for 0-10V dimming.

Construction & Durability

Built for the elements, the X34XLW features a precision die-cast aluminum housing finished in a durable white. The tempered glass lens and high-quality construction ensure an IP65 rating against dust and moisture. It safely operates in extreme temperatures ranging from -40°F (-40°C) up to 104°F (40°C).

Installation & Mounting

This model includes a pre-installed, robust slipfitter mount. The mount features a tilt increment of 10°, allowing for precise directional aiming when installed on standard poles or tenons.

What's Included

• RAB X34XLW LED Field-Adjustable Floodlight (White)
• Integrated Slipfitter Mount
• Integrated Selectable On/Off Photocell
