RAB VXBRLED26DG LED Vaporproof Wall Mount — Wet Rated Industrial Fixture

The RAB VXBRLED26DG is an LED vaporproof wall mount fixture engineered for wet and outdoor industrial environments. It delivers approximately 2,004 lumens at 26W with a fixed 4900K correlated color temperature on a universal 120–277V driver. Designed to replace up to a 200W incandescent, this fixture features a rugged die-cast aluminum housing, thermal shock-resistant frosted glass globe, and protective guard. It is UL listed for wet locations and rated to operate from -40°F to 104°F ambient.

Key Features

• Output: 2,004 lumens
• Wattage: 26W
• CCT: 4900K (cool)
• Voltage: 120–277V universal input
• Driver: Constant current, 100–277V, 50/60 Hz
• Power Factor: 97.9%
• Wet Location: UL listed for wet locations
• Operating Range: -40°F to 104°F (-40°C to 40°C)
• Rated Life: 100,000 hours (L70)
• Construction: Die-cast aluminum housing with silicone gaskets
• Globe & Guard: Frosted glass globe with protective guard
• TAA Compliant: Meets Trade Agreements Act requirements
• Warranty: 5-year manufacturer warranty

Typical Applications

• Exterior wall lighting
• Loading docks
• Utility and maintenance areas
• Outdoor corridors
• Stairwells with wet exposure
• Wet environment industrial spaces

Performance & Light Output

The VXBRLED26DG delivers approximately 2,004 lumens with an efficacy of ~73.9 lm/W. It provides consistent cool white illumination with ~68 CRI. LEDs are tested for >100,000 hours (L70) based on LM-80 and TM-21 projections.:contentReference[oaicite:1]{index=1}

Electrical & Controls

Operates on a universal 120–277V, 50/60 Hz constant current driver with ~97.9% power factor. Dimming is not specified for this model. Surge protection is inherent to fixture design.:contentReference[oaicite:2]{index=2}

Construction & Durability

All-die-cast aluminum housing with high-temperature silicone gaskets provides robust sealing for wet environments. The thermal shock-resistant frosted glass globe and integrated guard protect the light engine in rain, moisture, and washdown-adjacent conditions. Rated for wet locations and cold starts to -40°F (-40°C).:contentReference[oaicite:3]{index=3}

Installation & Mounting

Wall-mount design with (3) 1/2" NPS conduit entry points allows sealed conduit routing in exterior or industrial settings. Suitable for downlight and general illumination applications where wall mounting is required.:contentReference[oaicite:4]{index=4}

Included

• LED fixture
• Die-cast protective guard
• Frosted glass globe
