RAB Lighting VAN17 3-Way Adjustable Canopy Light 4500 Lumens 30W Selectable CCT 120-277V White
Available in stock (189)
About this item
About this item
- Wattage: The fixture offers selectable wattage options of 30W, 25W, and 20W for flexible power usage.
- Lumens: It delivers a light output ranging from 2,883 to 4,453 lumens, ensuring bright illumination.
- Color Temperature: Features selectable CCT options of 3000K, 4000K, and 5000K to suit various lighting needs.
- Ingress Protection: Rated IP65, making it suitable for wet locations and providing dust and water protection.
- Dimming Capability: Includes 0-10V dimming for adjustable light levels down to 10%.
We process payments securely and do not store credit card information.
Description
Description
RAB Lighting VAN17 3-Way Adjustable Canopy Light - 30W Configuration
The RAB Lighting VAN17-30W is a versatile canopy light offering selectable wattage options of 30W, 25W, and 20W and a light output of up to 4,453 lumens. It operates on a 120-277V input and features selectable CCT options of 3000K, 4000K, and 5000K. This fixture is DLC Premium listed, ensuring high efficiency and rebate eligibility.
Key Features
- Field Adjustability: Offers field adjustable wattage and CCT for customized lighting solutions.
- Photocell: Built-in on/off photocell with a factory default setting of off for automatic dusk-to-dawn operation.
- Durability: Constructed with precision die-cast aluminum housing and a vandal-resistant polycarbonate lens.
- Compliance: UL listed for wet locations and tested in accordance with IESNA LM-79 and LM-80 standards.
- Surge Protection: Equipped with 4kV line-to-neutral and 6kV line/neutral-to-ground surge protection.
- Power Factor: High power factor of 99.7% at 120V and 93.3% at 277V for efficient operation.
- Green Technology: Mercury and UV free, with RoHS-compliant components.
- Warranty: Backed by a 5-year limited warranty covering light output, driver performance, and paint finish.
Typical Applications
- Parking Garages
- Stairwells
- Passageways
- Loading Docks
- Industrial Facilities
Performance & Light Output
This fixture provides a luminous efficacy of 140.8-153.1 lm/W, ensuring efficient light distribution. It features a long-life LED with a 100,000-hour lifespan based on IES LM-80 results and TM-21 calculations.
Electrical & Controls
Operates on a 120-277V input with a constant current driver. It supports 0-10V dimming systems and includes a built-in photocell for dusk-to-dawn operation. The fixture also offers robust surge protection.
Construction & Durability
The housing is made from precision die-cast aluminum, and the lens is a vandal-resistant polycarbonate. It is IP65 rated for dust and water ingress protection, suitable for use in temperatures ranging from -40°C to 50°C.
Installation & Mounting
Designed for ceiling mounting with retrofit mounting plates included. The fixture is easy to install and adaptable to various applications.
What's Included
- RAB Lighting VAN17-30W Canopy Light
- Retrofit Mounting Plates
Specifications
Specifications
Dimensions
Style & Materials
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
