Description

RAB Lighting H-Type Track Flexible Connector Black

The RAB Lighting TK-F/B is a Black flexible connector that joins two compatible RAB H-Type track sections up to 90° left, right, up or down. Its flexible center accommodates changes in track direction in either a horizontal or vertical plane, while the Black end housings coordinate with matching rails.

Key Features

  • Two-section joining: Connects two compatible track sections.
  • Directional flexibility: Up to 90° left, right, up or down.
  • Track compatibility: For compatible RAB H-Type Halo track.
  • Overall length: 10 5/16 in. with the connector straight.
  • Body dimensions: 7 7/8 in. excluding projecting connections, 1 1/2 in. wide, 3/4 in. profile.
  • Finish: Black to coordinate with matching track components.

Compatibility & Function

The TK-F/B is a rail-to-rail flexible connector, rather than a light-head mounting adapter. It accommodates directional changes left or right and transitions up or down, with adjustment up to 90°. Use compatible RAB H-Type Halo rails and select the light heads and power-feed components required for the complete layout separately.

Dimensions & Installation

With the connector straight, the overall length is 10 5/16 in., including both projecting track connections. The body, including the flexible center but excluding those projecting connections, spans 7 7/8 in. The housings measure 1 1/2 in. wide, with a 3/4 in. side profile; the narrower projecting track connections are 3/4 in. wide. Allow clearance for the chosen bend and the connected rails when planning the installation.

Electrical & Installation

Disconnect power before installing or adjusting track components. Position the flexible connector within its 90° adjustment limit and connect the two compatible rail sections according to the track-system installation instructions. Maintain the required connection orientation and grounding, and secure the connections before restoring power.

What's Included

  • RAB Lighting TK-F/B Black flexible connector.

Specifications

Dimensions

Length/Depth
10.31 in
Width/Diameter
1.5 in
Height
0.75 in
Weight
0.4 lb

Style & Materials

Finish
Black

Item Details

MPN
TK-F/B
Brand
RAB Lighting
Family
RAB Track Light System
UPC
192552048392

Warranty & Certifications

Product Rating
Dry

Shipping & Returns

Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.

Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.

See Full Shipping Policy | See Full Return Policy

Frequently Asked Questions

What does the RAB Lighting TK-F/B flexible connector do?

The RAB Lighting TK-F/B connects two compatible track sections while accommodating a change in direction. It is a rail-to-rail flexible connector.

How far and in which directions can the RAB Lighting TK-F/B bend?

The RAB Lighting TK-F/B connects track sections up to 90° left, right, up or down. It accommodates horizontal or vertical changes in the track layout.

Which track is compatible with the RAB Lighting TK-F/B?

The RAB Lighting TK-F/B is for compatible RAB H-Type Halo track sections. Use matching track-system components for the installation.

What are the dimensions of the RAB Lighting TK-F/B?

The RAB Lighting TK-F/B measures 10 5/16 in. long overall when straight. Its body spans 7 7/8 in. excluding the projecting connections, with 1 1/2 in. wide housings and a 3/4 in. profile. The projecting track connections are 3/4 in. wide.

What comes with the RAB Lighting TK-F/B?

The RAB Lighting TK-F/B is the Black flexible connector. Rails, light heads and the power-feed components required for the layout are separate.
