RAB SUMOFA-7R-12-95CCT-UNVT-W 7 in LED Flush Mount — White, 12W, Selectable CCT

The RAB SUMOFA-7R-12-95CCT-UNVT-W integrated LED flush mount offers a sleek, low-profile design for new construction and retrofit spaces. Choose from five field-adjustable CCT settings and enjoy 950-1,020 lumens at 12W, depending on the selected color temperature. A white metal enclosure and polycarbonate diffuser create a clean look, while 120-277V input and compatible TRIAC/ELV dimming provide installation flexibility.

Key Features

• Selectable CCT: 2700K, 3000K, 3500K, 4000K or 5000K via DIP switch
• Setting-Specific Output: 950, 970, 1,000, 1,020 and 985 lumens respectively
• Wattage: 12W integrated LED; 60W incandescent equivalency
• Color Quality: Greater than 90 CRI, R9 at least 50 and 4-step MacAdam Ellipse consistency
• Beam: 110 degrees with ±10-degree tolerance
• Dimming: Down to 10% on compatible TRIAC/ELV systems
• Driver: Constant-current Class 2; 120-277V input
• Electrical Quality: THD at most 20%, power factor at least 0.9 and flicker at most 30%
• Construction: Round 7 in size, white metal enclosure, smooth trim and polycarbonate diffuser; 0.9 lb
• Listings: UL listed for dry, damp and wet environments; ENERGY STAR Version 1.0 certified; not IC rated or airtight
• Compliance: TAA, FCC Part 15 and RoHS compliant; sheet states suitability for conformity with California Title 24 Part 6; suitable for closet use under the listed NEC installation provisions
• Life and Warranty: 50,000-hour L70 lifespan; five-year warranty; -4°F to 104°F operating range

Construction & Design

The round 7 in surface-mount fixture pairs a white metal enclosure with smooth trim and a polycarbonate diffuser that distributes light evenly for general illumination. It weighs 0.9 lb. Its understated, low-profile design suits spaces where a pendant drop is undesirable.

Light Output & Performance

Output is 950 lumens at 2700K, 970 at 3000K, 1,000 at 3500K, 1,020 at 4000K and 985 at 5000K. Corresponding efficacy is 79, 81, 83, 85 and 82 lm/W. Greater than 90 CRI and R9 at least 50 support accurate color rendering, with a broad 110-degree beam and ±10-degree tolerance. Rated LED life is 50,000 hours at L70; separate bulbs are not required.

Electrical & Installation

The constant-current Class 2 driver accepts 120-277V. The fixture supports surface or recessed mounting options and dims down to 10% on compatible TRIAC/ELV systems. Select one of five CCT settings using the DIP switch during installation. Its low-profile format avoids the overhead drop of a hanging fixture. The fixture is UL listed for dry, damp and wet environments and suitable for closet installations under the NEC provisions listed on the sheet. It is not IC rated or airtight.

Compatible Accessories

• DAISY50: 50 ft extension cord with connectors

Typical Applications

• Residential hallways and entryways
• Utility and laundry areas
• Bathrooms
• Closets with installation under the listed NEC provisions

What's Included

• RAB SUMOFA-7R-12-95CCT-UNVT-W white fixture with integrated LED and polycarbonate diffuser
