RAB R3 CCT-Selectable 3 in Square Baffle Recessed Downlight
Available in stock (50)
-
Estimated delivery: Oct 24 - Oct 28
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. (Exclusions apply for oversized & commercial items). We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. (Exclusions: Special orders, clearance, and custom items).
We process payments securely and do not store credit card information.
Description
Description
RAB CCT-Selectable 3 in Square Baffle Recessed Downlight — 9W or 15W / Selectable CCT / 120V / White
RAB's 3 in square baffle recessed downlight series offers 9W (650 lm) or 15W (1,000 lm) options with a remote driver — no housing or J-box required. The square aperture suits modern and contemporary interiors. CCT is field-selectable 2700K–5000K via dip switch (default: 3000K). All models are IC rated, airtight per ASTM E283, and wet location rated. Install via spring-loaded retention clips in new construction or retrofit ceilings.
Series Overview
- RAB R3S-9B — 3 in / 9W / Square Baffle: 650 lm | 72.22 lm/W | 38° beam | 65W equiv | 77mA | MBCP: 1,395
- RAB R3S-15B — 3 in / 15W / Square Baffle: 1,000 lm | 66.67 lm/W | 38° beam | 125W equiv | 125mA | MBCP: 2,070
Shared Specifications
- CRI: 90+, R9 ≥ 50 | 4-step MacAdam Ellipse | Flicker ≤30%
- CCT: Field-selectable 2700K, 3000K, 3500K, 4000K, 5000K via dip switch (default: 3000K)
- Dimming: TRIAC/ELV to 10% at 120V
- Driver: Constant Current Class 2 remote driver, 120V
- THD: ≤25% | PF: ≥0.9
- IC Rated — airtight per ASTM E283 | Wet location rated
- No housing or J-box required — spring-loaded retention clips
- Weight: 1.0 lbs | Operating temp: -13°F to 104°F (-25°C to 40°C)
- Certifications: ETL Listed | ENERGY STAR v2.2 | Title 24 JA8 | RoHS | FCC Part 15B | NEC closet compliant
- Note: These products do NOT meet California Title 20 requirements
- Lifespan: 50,000 hours L70 | Warranty: 5-year no-compromise warranty
Construction & Design
Metal enclosure with white square baffle trim. Polycarbonate light diffuser. Remote Class 2 driver. Housing certified airtight per ASTM E283. IC rated for direct contact with insulation (not spray foam; consult NEMA LSD57-2013). Wet location rated.
Typical Applications
- Modern and contemporary interiors requiring a square ceiling aperture
- General and task lighting in residential new construction and remodels
- Retail and commercial general illumination
- Kitchens, bathrooms, hallways, and closets
- Wet, damp, and dry interior and covered outdoor environments
