RAB FXLEDMSF 346W Selectable LED Flood Light 48,128 Lumens 213-346W Selectable 30K/40K/50K Slipfitter Mount 120-277V Bronze

RAB FXLEDMSF Medium Field-Adjustable Floodlight — 346W, Selectable CCT & Power, Slipfitter Mount, 120-277V, Bronze

The RAB FXLEDMSF is a highly efficient, professional-grade LED flood light designed for massive light output and maximum flexibility in rugged outdoor environments. This versatile medium-sized fixture produces up to 48,128 lumens and allows installers to choose between two high-power levels (346W and 213W) and three color temperatures (3000K, 4000K, 5000K) directly in the field. It features a wide NEMA 7H x 6V beam spread, providing a broad, powerful wash of light ideal for building facades, large signs, and expansive landscape accents. Built for longevity, the FXLEDMSF is housed in precision die-cast aluminum with an ultra-clear tempered glass lens and earns a rigorous IP66 rating for superior durability against the elements. With an industry-leading 10-year warranty, standard 0-10V dimming, and a highly stable slipfitter mount, it is the perfect long-term solution for demanding exterior lighting applications.

Key Features

• Wattage: Field adjustable to 346W or 213W (factory default 346W).
• Selectable CCT: Field adjustable between 3000K (Warm), 4000K (Neutral), and 5000K (Cool).
• Dimming: Integrated 0-10V dimming capabilities, dimming down to 10%.
• NEMA Type: Wide NEMA 7H x 6V beam spread.
• Mounting Type: Heavy-duty slipfitter mount with 5° tilt increments.
• Compliance: DLC Premium Listed (Product ID: S-5YR4RW).
• Delivered Lumens: Up to 48,128 lumens at the 346W 4000K setting.
• Environmental Ratings: IP66 rated for dust and water; UL Listed for wet locations.
• Warranty: Industry-leading 10-year, no-compromise warranty.

Typical Applications

• Medium-to-large building perimeters and facade illumination
• Expansive landscape, monument, and flag pole lighting
• Commercial signage and billboards
• General high-output exterior area and security lighting

Performance & Light Output

The FXLEDMSF provides high-intensity, uniform light with a maximum output of 48,128 lumens. Its advanced optical design ensures excellent color consistency through 7-step MacAdam Ellipse binning. With long-life LEDs rated for 100,000 hours, this fixture significantly reduces maintenance and energy costs over time.

Electrical & Controls

Equipped with a Class 2 constant current driver, the FXLEDMSF is built for exceptionally stable performance on 120-277V systems. It supports standard 0-10V dimming for integration with motion sensors or building control systems to further enhance energy savings.

Construction & Durability

The fixture features a rugged die-cast aluminum housing finished in a durable bronze and sealed with high-temperature silicone gaskets. Its IP66 rating confirms total protection against dust and powerful water jets, safely operating in extreme starting temperatures down to -40°F (-40°C) up to 104°F (40°C) ambient.

Installation & Mounting

This model includes an integrated heavy-duty slipfitter mount, ideal for installations on standard poles or tenons. The mount features a 5° tilt increment for very precise and secure light aiming.

What's Included

• RAB FXLEDMSF LED Field-Adjustable Floodlight (Bronze)
• Integrated Slipfitter Mount
• 10-Year Manufacturer Warranty
