RAB EXITOUT Outdoor Exit Sign — AC Only, 120/277V

The RAB EXITOUT-G is a rugged, outdoor-rated exit sign featuring green letters designed exclusively for AC only applications. Running continuously on a 120/277V input, this fixture is perfectly suited for commercial buildings supported by central emergency generators. By completely sealing out moisture, it ensures strict compliance with OSHA and NFPA life safety codes even in the most demanding wet exterior environments.

Key Features

• Housing Material: Highly durable, impact-resistant thermoplastic withstands environmental abuse.
• Face Configuration: Single-face panel designed for secure surface mounting.
• Emergency Runtime: AC only operation relies on facility generator power.
• Letter Color: Bright green letters for high contrast visibility.
• Environmental Rating: Wet location rated for total outdoor exposure.
• Input Voltage: Dual 120/277V capability for commercial electrical circuits.
• Mounting Options: Back, top, or end mount capable for architectural flexibility.
• Operating Temperature: Extreme cold rated down to -4°F (-20°C).

Performance & Illumination

This exit sign relies on an ultra-efficient 2.7W LED array to provide a crisp, continuously illuminated green face. Standardized 6-inch high lettering ensures optimal readability from a distance, guiding occupants safely toward the exterior of the building. The diffuse optical panel minimizes hot spots, offering a smooth and consistent glow that stands out clearly in both low-light and bright daytime conditions.

Electrical & Battery

Operating strictly on AC power, this unit accepts a standard dual 120/277V input with a high power factor of ?0.9. Because it is an AC-only model, it does not contain an internal battery backup system. It relies entirely on the facility's localized power grid or an external central inverter/generator system to maintain illumination during a primary power failure.

Physical & Installation Details

The sealed white thermoplastic housing provides robust protection against the elements. Designed for extreme versatility, the unit supports back, top, or end mounting configurations to adapt to a wide variety of architectural requirements. It is a single-face design intended specifically for flush mounting against walls or over exterior doorframes.

Compliance & Safety

The fixture is thoroughly UL924 Listed and meets stringent NFPA 101, NEC, and OSHA standards. It is explicitly rated for wet locations, enduring heavy rain and extreme cold weather operation down to -4°F (-20°C). Furthermore, it is fully California Title 20 compliant, cementing its status as an energy-conscious safety device.

What's Included

• (1) Outdoor AC-Only Exit Sign
• Mounting Canopy and Hardware
