RAB CR4/E 4 in. Open Deep Regressed Downlight 11W 1000 Lumens Selectable CCT, Emergency Battery Included
Available in stock (100)
About this item
About this item
- Selectable CCT: Choose from 2700K, 3000K, 3500K, 4000K, or 5000K for versatile lighting options.
- High Lumens: Delivers up to 1000 lumens for bright illumination.
- Energy Efficient: Operates at 11W, equivalent to a 23W CFL.
- Emergency Battery Backup:Integrated, quick connect battery backup system, minimum of 90 minutes of power during emergency operation.
- Dimmable: Compatible with TRIAC/ELV and 0-10V dimming systems for adjustable brightness.
We process payments securely and do not store credit card information.
Description
Description
RAB CR4/E 4 in. Open Deep Regressed Downlight With Integrated Emergency Battery Backup — 11W / Selectable CCT
The RAB CR4/E is a versatile 4-inch commercial downlight delivering 1000 lumens using 11W. This model features a selectable CCT ranging from 2700K to 5000K, making it adaptable for various lighting needs. The open, deep regressed trim design ensures optimal glare control, while the wet rating allows for installation in diverse environments.
Key Features
- Wattage: 11W
- Lumens: 1000 lm
- Voltage: 120-277V
- Dimming: TRIAC/ELV and 0-10V dimming
- Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K
- CRI: 90
- Beam Angle: 85°±10°
- Lifespan: 50,000 hours
- Compliance: ENERGY STAR, Title 24 JA8, RoHS
- Construction: Spun aluminum with polycarbonate diffuser
- Mounting: Spring action clips for easy installation
- Emergency Battery Backup:Integrated, quick connect battery backup system, minimum of 90 minutes of power during emergency operation.
Construction & Aesthetics
Constructed from spun aluminum, the CR4/E features a smooth splay reflector and a polycarbonate light diffuser for even light distribution. Available accessories include color trim rings and mounting plates for enhanced aesthetic customization.
Electrical & Installation
Operating on 120-277V, this downlight supports universal dimming and is equipped with an integrated driver. Installation is simplified with stainless steel spring action clips, suitable for ceiling thicknesses from 1/2'' to 2''.
Light Output & Performance
With a high CRI of 90 and a beam angle of 85°±10°, the CR4/E ensures vibrant and consistent lighting. The LED lifespan is rated at 50,000 hours, providing long-term performance.
Typical Applications
- Commercial spaces
- Residential areas
- Bathrooms
- Outdoor patios
- Retail environments
Specifications
Specifications
Dimensions
Documents
Style & Materials
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the wattage equivalency of the RAB CR4/E?
What is the wattage equivalency of the RAB CR4/E?
Can the RAB CR4/E be used in wet locations?
Can the RAB CR4/E be used in wet locations?
How is the RAB CR4/E installed?
How is the RAB CR4/E installed?
Does the RAB CR4/E support dimming?
Does the RAB CR4/E support dimming?
What accessories are available for the RAB CR4/E?
What accessories are available for the RAB CR4/E?
