RAB CRX High-Output Field-Adjustable Commercial Downlight — 3 / 4 / 6 / 8 in | Selectable Wattage & CCT | 120-277V
The RAB CRX family is a high-output, field-adjustable commercial canless recessed downlight available in 3 in, 4 in, 6 in, and 8 in aperture sizes. Each size features field-selectable wattage and CCT (2700K–5000K) via integrated dipswitches — eliminating the need to stock multiple SKUs. Universal 120-277V input, dual dimming compatibility (0-10V and TRIAC/ELV), and a wide 85° beam angle make the CRX family ideal for commercial, hospitality, and high-end residential applications of all scales. White smooth splay trim with flange included on all sizes; interchangeable matte black, brushed nickel, and bronze color trim overlays available separately for 4 in, 6 in, and 8 in.
Key Features
- Field-Selectable Wattage: Choose wattage at installation via dipswitch — 3 in: 9/12/15W; 4 in: 12/16/20W; 6 in: 30/40/50W; 8 in: 50/65/80W
- Field-Selectable CCT: Dip-switch adjustable between 2700K, 3000K, 3500K, 4000K, and 5000K on all sizes
- Lumen Output by Size: 3 in up to 1,685 lm | 4 in up to 2,245 lm | 6 in up to 5,720 lm | 8 in up to 9,146 lm (all at peak wattage / 4000K)
- CRI: 90 with R9 > 50 for high color accuracy
- Beam Angle: 85° ±10% for broad, even illumination
- Dimming: 0-10V dimmable to 10%; TRIAC/ELV dimmable to 10% at 120V
- Voltage: 120-277V universal on all sizes
- No Housing Required: Canless design with remote driver/junction box — installs directly into ceiling
- Trim: White smooth splay trim with flange included; matte black, brushed nickel, and bronze color trim overlays sold separately (4 in, 6 in, 8 in only)
- IC Rating: IC rated (3 in & 4 in); Not IC rated — maintain insulation clearance (6 in & 8 in)
- Certifications: ENERGY STAR, Title 24 JA8, ETL/UL listed, RoHS compliant, NEC compliant (Sec. 410.16)
- Warranty: 5-year no-compromise warranty
Smart & Control Features
All CRX sizes dim to 10% on compatible 0-10V dimming systems and on TRIAC/ELV dimming systems at 120V. Both wattage and CCT are field-adjustable via integrated dipswitches on the remote driver/junction box at installation — no SKU change required. Compatible emergency driver: DRI-21-EMGR-DC-D10; emergency driver T20.
Construction & Design
Each CRX fixture features a metal enclosure with a white smooth splay trim and flange and a deep-regress frosted polycarbonate lens for even light distribution and glare reduction. The 4 in, 6 in, and 8 in sizes accept interchangeable color trim overlays in matte black, brushed nickel, and bronze (sold separately) for design flexibility.
Light Output & Performance by Size
- 3 in (9/12/15W): Up to 1,685 lm | Up to 121 lm/W | 40W CFL equiv.
- 4 in (12/16/20W): Up to 2,245 lm | Up to 118 lm/W | 52W CFL equiv.
- 6 in (30/40/50W): Up to 5,720 lm | Up to 118 lm/W | 125W CFL equiv.
- 8 in (50/65/80W): Up to 9,146 lm | Up to 116 lm/W | 200W CFL equiv.
All sizes: 90 CRI, R9 > 50, 85° beam angle, 50,000-hour L70 lifespan per IES LM-70.
Electrical & Installation
All sizes operate on 120-277V with a Constant Current, Class A driver. Dimmable to 10% via 0-10V or TRIAC/ELV systems. The remote driver/junction box installs easily with quick snap-in connectors — no recessed housing needed. Suitable for new construction, remodel, and retrofit. 3 in and 4 in are IC rated and airtight certified (ASTM E283). 6 in and 8 in are not IC rated — maintain clearance from insulation per NEMA LSD57-2013; airtight certified (ASTM E283). Operating temperature: -4°F to 104°F.
What’s Included
- RAB CRX commercial downlight (size per variant selected, white finish)
- Remote driver/junction box
- Quick snap-in connectors
- Mounting hardware
- Compatible accessories: size-specific mounting plate with nailer bar and drywall collar; DRI-21-EMGR-DC-D10 emergency driver; color trim overlays in matte black, brushed nickel, bronze for 4/6/8 in (all sold separately)
