Satco Nuvo TH403 Round 12W H-Type LED Track Head 3000K 36 Degree Matte White
Available in stock (1095)
About this item
About this item
- Broader Accent Beam: Fixed 36° spread, 1020 lumens from 12W, 85 lm/W.
- Warm Color Quality: Fixed 3000K warm white light with 90+ CRI.
- Directional Design: Articulating round head, matte white die-cast aluminum housing and PMMA lens.
- Dimming Control: Compatible 120V phase-cut dimmers, 60Hz operation.
- Matched Track System: H-Type adapter for Satco Nuvo H-Style track, dry indoor use, 30,000-hour L70 life.
Description
Description
Satco Nuvo TH403 Round LED Track Head
The Satco Nuvo TH403 brings 3000K warm white light to residential and commercial interiors with a fixed 36° beam for broader accents than the collection's 24° models. Its 12W integrated LED delivers 1020 lumens, with 90+ CRI for detailed color rendering. A matte white die-cast aluminum housing and articulating round head combine contemporary styling with directional illumination. Designed for Satco Nuvo H-Style track, it supports compatible 120V phase-cut dimming.
Key Features
- Track System: H-Type adapter, designed for Satco Nuvo H-Style track.
- Light Source: 12W integrated LED, no separate lamp required.
- Light Output: 1020 lumens, 85 lm/W.
- Color Temperature: Fixed 3000K warm white.
- Color Rendering: 90+ CRI.
- Beam: Fixed 36° spread, articulating head for directional aiming.
- Construction: Die-cast aluminum, matte white finish, PMMA lens.
- Electrical: 120V, 60Hz, 0.10A, power factor greater than 0.9.
- Dimming: Compatible 120V phase-cut dimmers.
- Rated Life: 30,000 hours L70.
- Location & Listings: Dry indoor locations, cETLus Listed, FCC and RoHS compliant, Title 24 compliant.
- Operating Temperature: -4°F to 104°F (-20°C to 40°C).
Construction & Design
The round head combines a matte white die-cast aluminum body with a polymethyl methacrylate (PMMA) lens. Overall height is 6.25 in and body depth is 2.25 in. Articulation directs the head toward displays or architectural details without changing the fixed optical beam.
Light Output & Performance
The integrated LED produces 1020 lumens at 12W, equivalent to 85 lm/W. Its 3000K color temperature and 36° beam are fixed, while 90+ CRI supports natural-looking colors. Rated functional life is 30,000 hours L70. Compatible phase-cut dimming lets you adjust brightness for the space.
Electrical & Installation
The Satco Nuvo TH403 operates at 120V, 60Hz, draws 0.10A and has a power factor greater than 0.9. It uses an H-Type track adapter and must be used with Satco Nuvo H-Style track systems to maintain the cETLus listing and warranty requirements. Dimming is supported with compatible 120V phase-cut dimmers. Install in dry indoor locations within the -4°F to 104°F operating range. Track and system components are sold separately.
Compatible Accessories
Matching white Satco Nuvo track-system components, sold separately. Choose rails, a suitable power feed and connectors for your layout.
- Track Rails: TR118 (2 ft), TR120 (4 ft), TR124 (6 ft) and TR122 (8 ft), single circuit H-Type.
- Power Feeds: TP152 live end and canopy, TP154 floating canopy, TP156 live end cord kit, TP169 conduit live end and TP171 inline feed.
- Track Connectors: TP144 mini straight, TP146 L, TP148 T, TP150 X and TP167 flexible connector.
- Track Mounting: TP240 white aircraft cable suspension, TP185 silver drop-ceiling T-bar clips (4 pack) and TP243 replacement mounting hardware (2 screws and 2 toggle bolts).
Typical Applications
- Residential artwork and display accents.
- Retail merchandise lighting.
- Gallery accent lighting.
- Commercial interior architectural accents.
What's Included
- Satco Nuvo TH403 matte white round track head with integrated LED and H-Type track adapter.
