Satco 65-1081 2ft Ceiling LED Wrap — 20W — 4000K — 100–277V — White
Available in stock (19)
About this item
About this item
- 90+ CRI Output & Equivalency: Delivers 1,600 lumens at 20W (80 lm/W efficacy) with 90+ CRI color accuracy to replace 100W incandescent utility fixtures.
- Slim Steel Wrap Profile: Maintenance-free steel housing with even light distribution mounts directly to a junction box or wires via the built-in junction box.
- 4000K Cool White Illumination: Dedicated 4000K cool white LED array with 90+ CRI ensures crisp, true-to-life color rendering across workspaces and storage areas.
- Direct or Built-In J-Box Wiring: Non-dimmable driver mounts directly over an existing junction box or wires internally via the built-in junction box.
- Closet & Damp Location Certified: Certified to NEC 410.16(A)(3) and 410.16(C)(5) clothes closet regulations, cETLus damp rated, and Title 20 exempt.
Description
Description
Satco 65-1081 2ft Ceiling LED Wrap — 20W — 4000K — 100–277V — White
The Satco 65-1081 is a commercial and utility 2ft LED Ceiling Wrap Fixture engineered to deliver 1,600 lumens at 20W (80 lm/W) in a dedicated 4000K cool white color temperature with 90+ CRI color rendering. Operating on 100–277V (120–277V) (50/60Hz) electrical systems with non-dimmable direct-wired operation, this luminaire provides an energy-efficient replacement for legacy 100W incandescent utility fixtures. Built with a cETLus Listed damp location rating and NEC 410.16(A)(3) & 410.16(C)(5) clothes closet certification, it features a slim steel housing with a built-in junction box for direct or internal wiring.
Key Features
- Wattage: 20W fixed output
- Wattage Equivalency: Replaces 100W incandescent fixtures
- Maximum Lumen Output: 1,600 lm at 20W (4000K)
- Peak Efficacy: 80 lm/W
- CRI: 90+ CRI for high-accuracy color rendering
- Color Temperature: 4000K (Cool White)
- Dimming: Non-dimmable
- Voltage & Current: 100–277V (120–277V) AC, 50/60Hz (0.200A–0.072A, Power Factor 0.99)
- Location & Closet Rating: cETLus Listed for damp locations; NEC Clothes Closet Certified per Reg. 410.16(A)(3) and 410.16(C)(5)
- Operating Temperature: -4°F (-20°C) to 113°F (45°C) ambient range
- Certifications: cETLus Listed, NEC 410.16 Certified, FCC Compliant, RoHS Compliant, California Title 20 Exempt
- Rated Life: 50,000 hours
- Warranty: 5-year limited warranty — Satco
Performance & Light Output
At 20W: Delivers 1,600 lumens at 4000K (Cool White) with an efficacy of 80 lm/W, replacing legacy 100W incandescent fixtures.
CRI 90+ across operation. Rated life 50,000 hours.
Electrical
Powered by a direct-wired non-dimmable driver operating on 100–277V (120–277V) AC at 50/60Hz with a Power Factor of 0.99 and operating current of 0.200A–0.072A.
Operating current and amp draw for branch circuit and breaker loading calculations:
| Wattage | Operating Current (Amps) |
|---|---|
| 20W | 0.200A–0.072A ( across 120V–277V ) |
Construction
Housing & Build: Slim white steel housing with an integrated built-in junction box that mounts directly to an external junction box or wires internally.
Location & Environmental Rating: cETLus Listed for indoor damp locations and Clothes Closet Certified under NEC 410.16(A)(3) and 410.16(C)(5).
Operating Temperature: Operating ambient temperature range of -4°F (-20°C) to 113°F (45°C).
Lens & Optics: Wraparound diffuser engineered for even, maintenance-free light distribution with no bulbs to change.
Finish: White finish formulated for clean indoor ceiling or wall integration.
Dimensions & Weight: 24.50" L × 5.50" W × 2.63" H (EA: 24.75" × 5.51" × 2.63"). Fixture weight: 2.51 lbs.
Installation & Mounting
Standard Mounting: Ceiling or Wall Surface Mount. Mounts directly to a standard junction box or can be internally wired using the built-in junction box.
Certifications & Rebates
- cETLus Listed: Certified for indoor damp locations (Item 65-1081, UPC 045923510816).
- NEC 410.16 Closet Certified: Complies with NEC 410.16(A)(3) and 410.16(C)(5) clothes closet regulations.
- California Title 20: Title 20 Exempt — lawful for sale in California.
- FCC Compliant: Meets FCC electromagnetic interference standards.
- RoHS Compliant: Engineered free of hazardous substances.
Typical Applications
- Clothes Closets & Storage Areas — NEC 410.16(A)(3) & (C)(5) certification ensures code-compliant installation in enclosed closet spaces.
- Kitchens & Laundry Rooms — 90+ CRI color accuracy and cETLus damp rating provide crisp, reliable task lighting in humid rooms.
- Work Areas & Utility Rooms — Built-in junction box and direct-wire design simplify surface installation over workbenches.
- Hallways & Corridors — Slim low-profile wraparound diffuser delivers even pathway illumination across 50,000 rated hours.
- Multi-Family & Light Commercial Retrofits — Replaces legacy 100W–175W incandescent utility fixtures with a maintenance-free integrated LED design.
What's Included
- Satco 65-1081 2ft 20W 4000K LED Ceiling Wrap Fixture — White
- Built-in junction box
- Installation instructions
