Modern Forms Zephyr 72 in Outdoor LED Smart Ceiling Fan — Bronze / White Oak

The Modern Forms Zephyr (model FR-W2006-72L-BZ/WO) is a 72-inch smart ceiling fan engineered for large indoor and outdoor spaces. Powered by a whisper-quiet 120×25 sensorless DC motor with 6 fan speeds, it delivers up to 8,554 CFM of airflow at just 33W — making it one of the most efficient large-span fans available. The integrated LED luminaire outputs up to 2,159 lumens with selectable color temperatures from 2700K to 5000K, adapting to any lighting mood. UL/cUL Wet Location rated and Title 20 / Energy Star compliant.

Key Features

• Blade Span: 72 inches | 16° pitch | 72 in sweep
• Motor: Silent 120×25 sensorless DC | 6 speeds | Summer & Winter modes
• Airflow: 6,159 CFM (avg) / 8,554 CFM (high)
• Efficiency: 263 CFM/W (weighted average/high)
• Total Power: 54W (fan 33W + light 21W)
• Location Rating: UL/cUL Wet Location listed | Title 24 JA8-2016 | Title 20 | Energy Star
• Mounting Slope: Up to 30° included | Up to 45° with optional XF-SCK kit
• Downrod: 3/4 in W × 8 in H included | Wire: 80 in
• Hanging Weight: 17 lbs | Construction: Aluminum and ABS

Smart & Control Features

Includes a Bluetooth remote control (F-RCBT) for full fan speed and light brightness control, Summer/Winter mode switching, and wall cradle mounting. Pairs with the Modern Forms app for smartphone control and integrates natively with Amazon Alexa, Google Assistant, Control4, Crestron, JOSH, Samsung SmartThings, Bluetooth and Wi-Fi (up to 150 ft range each). Optional Bluetooth wall control (F-WCBT) available separately.

Construction & Design

The Bronze housing pairs with aerodynamically optimized White Oak blades at a 16° pitch for maximum airflow efficiency. Artisan-crafted with thick, soundless blade construction. Available in four finishes: Bronze/White Oak, Graphite/Weathered Wood, Matte Black/Distressed Koa, and Matte White/Matte White.

Light Output & Performance

The integrated LED luminaire delivers 1,991–2,159 lumens with a CRI of 90 and a rated life of 50,000 hours. Color temperature is fully selectable between 2700K, 3000K, 4000K, and 5000K. The light is fully dimmable via the included remote or Modern Forms app.

Electrical & Installation

Operates at 120V. Includes 8 in downrod and standard mounting hardware for flat or sloped ceilings up to 30°. For steeper slopes up to 45° (12/12 pitch), the optional XF-SCK Sloped Ceiling Kit is available separately. Maximum recommended downrod length is 72 in with 80 in lead wire.

Suggested Downrod by Ceiling Height

• 15 ft ceiling → 72 in downrod
• 14 ft → 60 in | 13 ft → 48 in | 12 ft → 36 in
• 11 ft → 24 in | 10 ft → 18 in | 9 ft → 12 in

Optional Accessories

• F-WCBT — Bluetooth Wall Control
• XF-12 through XF-72 — Downrods (12 in to 72 in, 0.75 in diameter)
• XF-I — Downrod Coupler
• XF-SCK — Sloped Ceiling Kit (up to 45° / 12/12 pitch)

What's Included

• 72 in ceiling fan with integrated LED luminaire
• Bluetooth remote control (F-RCBT-WT)
• 8 in downrod (3/4 in diameter)
• Mounting hardware
