Modern Forms Crown 62 in Smart DC Ceiling Fan with LED Light Soft Brass Matte Black

The Modern Forms Crown FR-D2602-62L-SB/MB combines a Soft Brass housing, five Matte Black ABS blades and a hand-carved natural Spanish alabaster diffuser. Its 62 in span and reversible DC motor deliver 7,618 CFM on high with six speeds. Damp Rated construction suits interiors and covered outdoor spaces. Integrated LED uplight and downlight offer selectable/tunable white lighting from 2700K to 5000K, while the included Bluetooth remote and MyWAC app provide smart control.

Key Features

• Blade Configuration: Five ABS blades; 62 in sweep and 13° pitch.
• Motor: 108 × 20 sensorless DC motor; six speeds, summer/winter modes and maximum 139 RPM.
• Airflow: 7,618 CFM on high; 5,063 CFM weighted average.
• Motor Power: 36W on high; 24W weighted average.
• Airflow Efficiency: 212 CFM/W high-speed efficiency in the supplied energy guide; 211 CFM/W weighted average.
• Downlight: 30W LED; 3,687–3,846 source lumens depending on CCT.
• Uplight: 16W LED; 1,495–1,678 source lumens depending on CCT.
• Color Quality: 90 CRI; selectable/tunable 2700K, 3000K, 3500K, 4000K and 5000K; integrated dimming.
• LED Life: 50,000-hour rated life.
• Location Rating: UL/cUL Damp Location listed; Soft Brass is not intended for coastal environments.
• Mounting: Slopes up to 30°; optional XF-SCK kit supports up to 45°, sold separately.
• Downrod & Weight: Included 6 in downrod with 0.75 in inside diameter; 17 lb hanging weight.
• Controls: Included F4-RCUBT-WT Bluetooth remote; optional F4-WCUBT-WT wall control, sold separately.

Smart & Control Features

The included F4-RCUBT-WT Bluetooth remote controls six speeds, light brightness and summer/winter modes. Wi-Fi and Bluetooth connectivity supports the MyWAC app. Voice integrations include Amazon Alexa and Google Assistant; supported smart-home integrations include Control4 and JOSH. The compatible F4-WCUBT-WT Bluetooth wall control is sold separately and supports multiple control locations.

Construction & Design

An aluminum housing in Soft Brass pairs with five Matte Black ABS blades. Natural Spanish alabaster diffuses the downlight, while an integrated uplight illuminates above the fan for layered lighting. The Soft Brass finish is not intended for coastal environments.

Light Output & Performance

The 30W LED downlight provides 3,687–3,846 source lumens; the 16W LED uplight provides 1,495–1,678 source lumens, depending on CCT. Both feature 90 CRI, 50,000-hour rated life and selectable/tunable 2700K, 3000K, 3500K, 4000K and 5000K lighting. Integrated dimming supports brightness control through the remote and connected app. Fan airflow reaches 7,618 CFM on high.

Electrical & Installation

The reversible DC motor uses 36W on high. A 6 in downrod with 0.75 in inside diameter is included. Standard mounting supports slopes up to 30°. For steeper ceilings up to 45°, use the compatible XF-SCK sloped-ceiling kit, sold separately. Install indoors or in covered outdoor damp locations, away from coastal environments.

Suggested Downrod by Ceiling Height

Ships with a 6 in downrod. Longer compatible downrods are available separately.

• 9 ft ceiling: 12 in downrod
• 10 ft ceiling: 18 in downrod
• 11 ft ceiling: 24 in downrod
• 12 ft ceiling: 36 in downrod
• 13 ft ceiling: 48 in downrod
• 14 ft ceiling: 60 in downrod
• 15 ft ceiling: 72 in downrod

What's Included

• Crown fan with Soft Brass housing and five Matte Black blades
• LED uplight and downlight with alabaster diffuser
• F4-RCUBT-WT Bluetooth remote
• 6 in downrod
• Mounting Hardware
