LSI Scottsdale Series Canopy Light - 102W Configuration

The LSI SCV-LED-15L-SC-UNV-DIM-50-WHT is a canopy light designed for high-performance lighting with 15,000 lumens output at 102 watts. It operates on a 120-277V input and features a 5000K color temperature, making it suitable for various canopy applications. This model is DLC Premium certified, ensuring energy efficiency and compliance with industry standards.

Key Features

• Optical System: Utilizes a symmetrical distribution with a clear tempered glass lens for uniform illumination.
• Driver Protection: Includes over-voltage, under-voltage, short circuit, and over-temperature protection.
• Surge Protection: Integral 6kV surge protection with an optional 10kV field replaceable device.
• Dimming Capability: Standard 0-10V dimming from 10% to 100% for flexible lighting control.
• Durable Finish: LSI's DuraGrip polyester powder coat finish withstands extreme weather conditions.
• Serviceability: Below canopy access to optical chamber and driver housing for easy maintenance.
• LED Configuration: High-efficacy LEDs mounted on four circuit boards for optimal heat dissipation.
• Temperature Range: Operates efficiently in temperatures from -40°C to +50°C.
• Power Factor: Greater than 0.90, ensuring efficient power usage.
• Compliance: Meets UL 1598 and UL 8750 standards, and is Buy American Act compliant.

Typical Applications

• Gas Station Canopies
• Convenience Store Exteriors
• Parking Structures
• Service Stations
• Commercial Canopy Installations

Performance & Light Output

This fixture provides a luminous efficacy of 147 lumens per watt, with a minimum CRI of 80, ensuring high-quality light output. The L80 calculated life exceeds 100,000 hours, providing long-term reliability.

Electrical & Controls

Designed with a factory programmable driver, the fixture includes integral surge protection and supports 0-10V dimming. It is compatible with optional Bluetooth motion and photocell sensors for enhanced control.

Construction & Durability

The fixture's die-cast aluminum housing is IP66 rated, offering robust protection against environmental factors. The DuraGrip finish ensures longevity against weather changes.

Installation & Mounting

Designed for easy installation in 12' or 16' deck pans, it includes an aluminum locking collar and gasket for a secure fit. Retrofit panels and direct mount accessories are available for various configurations.

What's Included

• Canopy Light Fixture
• Aluminum Locking Collar
• Gasket
