LED Gas Station Canopy Light, 11150 Lumens, 73 Watts, 5000K, 120-277V, Surface Mount
Made to Order
About this item
About this item
- Lumens: Delivers 11000 lumens for bright and efficient lighting.
- Wattage: Operates at 73 watts, ensuring energy efficiency.
- Voltage: Compatible with 120-277V for versatile installation.
- Color Temperature: 5000K provides a crisp, daylight-like illumination.
- Environmental Rating: IP67 rated for wet locations, ensuring durability in harsh conditions.
We process payments securely and do not store credit card information.
Description
Description
LSI Scottsdale Series Canopy Light - 73W Configuration
The LSI CRUS-SM-SC-LED-LW-50-UE-WHT is a canopy light designed to deliver 11000 lumens at 73 watts, operating on a 120-277V power supply. This fixture is ideal for applications requiring robust and efficient lighting solutions, and it is IP67 rated for wet locations.
Key Features
- Construction: Features a slim die-cast housing with a tempered glass lens, ensuring durability and resistance to environmental factors.
- Optical System: Utilizes high-efficiency LEDs with a symmetric distribution for uniform light output.
- Driver Protection: Includes a factory programmable driver with over-voltage and short-circuit protection.
- Surge Protection: Equipped with a 6kV surge protection device, meeting IEEE and ANSI standards.
- Dimming Capability: Standard 0-10V dimming allows for adjustable light levels.
- Operating Temperature: Functions efficiently in temperatures ranging from -40°C to 55°C.
- Finish: White DuraGrip polyester powder coat finish resists cracking and peeling.
- Compliance: UL and ETL listed, meeting international safety standards.
Typical Applications
- Gas Stations
- Parking Garages
- Loading Docks
- Retail Entrances
- Service Stations
Performance & Light Output
This fixture provides 11000 lumens with an efficacy of 154 lumens per watt, ensuring high performance. It features a CRI of 80, maintaining color accuracy and consistency over its lifespan.
Electrical & Controls
The canopy light operates on a universal voltage of 120-277V with a high-performance driver that includes integral surge protection. It supports 0-10V dimming for flexible control.
Construction & Durability
Constructed with a die-cast aluminum housing and a clear tempered glass lens, this fixture is IP67 rated, ensuring protection against dust and water ingress.
Installation & Mounting
Designed for easy installation, the fixture includes a tether for pre-assembled optical units and a hinged adaptor panel for simplified wiring.
What's Included
- Canopy Light Fixture
- Pre-mounted Driver
Specifications
Specifications
Dimensions
Documents
Style & Materials
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
