radiant R26USBPD65I 15A Tamper-Resistant 65W USB Type-C Power Delivery Duplex Outlet, Ivory
Available in stock (24)
About this item
About this item
- Amperage and NEMA Configuration: Features a standard 15A 125V rating in a NEMA 5-15R duplex configuration designed for residential and commercial branch circuits.
- 65W USB Power Delivery: Provides up to 65W of fast USB Type-C Power Delivery output to charge modern laptops, smartphones, and tablets without power adapters.
- Tamper-Resistant Safety: Incorporates dual internal shutter mechanisms that restrict access to energized contacts unless a two-prong plug is inserted.
- Durable Thermoplastic Body: Constructed from high-impact resistant thermoplastic with an elegant ivory finish for long-lasting durability in high-traffic areas.
- Back and Side Terminal Options: Features clamp-type back wire terminals and side wire screws accommodating up to #10 AWG solid or stranded copper wire.
Description
Description
Legrand radiant 15A 65W USB Type-C Power Delivery Duplex Outlet — Ivory & Tamper-Resistant
The Legrand R26USBPD65I radiant duplex receptacle delivers high-speed charging and reliable power distribution in a classic ivory finish. Rated for 15A and 125V with a NEMA 5-15R rating, this specification-grade device features 65W USB Type-C Power Delivery and built-in Tamper-Resistant safety protection.
Key Features
- Voltage Rating: 125V AC
- Amperage Rating: 15A
- NEMA Configuration: NEMA 5-15R
- Tamper-Resistant: Yes
- Weather-Resistant/Outdoor: No
- Grade: Commercial/Residential Specification Grade
- Overall Dimensions: 1.43 in. W x 1.70 in. D x 4.20 in. H
- Certifications: cULus Listed to UL498 and UL1310
- USB Port Configuration: Features 1 high-speed USB Type-C charging port
- USB Power Delivery Wattage: Delivers up to 65W PD charging output
Construction & Interface
Featuring the refined decorator styling of the radiant line, this receptacle is molded from tough, impact-resistant thermoplastic in a traditional ivory shade. The face matches standard decorator cutouts, and the decorative wallplate is sold separately to complete the physical installation.
Power & USB Charging
Equipped with an integrated USB Type-C port, this outlet utilizes Power Delivery (PD) technology to output up to 65W for rapid charging of demanding electronics like laptops. The AC duplex slots are protected by patented tamper-resistant shutters that block foreign object entry for code-compliant safety.
Wiring & Installation
Built for simple contractor setup, the unit includes combination back-wire pressure plates and traditional side-wire terminal screws that accept #14 to #10 AWG solid or stranded copper wire. A heavy-duty steel mounting strap ensures rigid, flush placement within electrical junction boxes.
Specifications
Specifications
Dimensions
Style & Materials
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
Is the wallplate included with the Pass & Seymour R26USBPD65I outlet?
Is the wallplate included with the Pass & Seymour R26USBPD65I outlet?
Can the USB Type-C port on the R26USBPD65I charge a laptop?
Can the USB Type-C port on the R26USBPD65I charge a laptop?
Is the R26USBPD65I tamper-resistant?
Is the R26USBPD65I tamper-resistant?
What wire size does the R26USBPD65I terminal support?
What wire size does the R26USBPD65I terminal support?
What is the electrical rating of the R26USBPD65I duplex outlet?
What is the electrical rating of the R26USBPD65I duplex outlet?
