GM Lighting PSD Series 60W 24VDC LED Driver TRIAC Dimmable
In stock
About this item
About this item
- Output Voltage & Power: Delivers 60W of 24VDC constant voltage power for LED tape and puck lights.
- Dimming Protocol: Features flicker-free Phase/TRIAC dimming from 20% to 100% range.
- Input Voltage: Standard 120VAC input designed for residential and commercial hardwire applications.
- Enclosure Type: Features an Integrated Junction Box for simplified wiring and installation without extra components.
- Protection Features: Built-in short circuit and over-voltage protection with a Class 2 safety rating.
We process payments securely and do not store credit card information.
Description
Description
GM Lighting PSD Series 60W LED Driver — 24VDC
The GM Lighting PSD60-24 is a high-performance 60W LED Driver designed to provide a reliable 24VDC Constant Voltage output for professional lighting applications. This 120V input driver features TRIAC dimming and includes an Integrated Junction Box for streamlined hardwire installation in damp locations. The PSD60-24 ensures flicker-free performance when used with compatible dimmers and LED systems.
Key Features
- Power Output: 60W
- Input Voltage: 120VAC
- Output Voltage: 24VDC
- Dimming Type: Phase/TRIAC
- Minimum Load: 40% (24W) for optimal performance
- Dimensions: 7.125 in. L x 3.375 in. W x 1.375 in. H
- Enclosure Type: Integrated Junction Box
- Safety Rating: Class 2 Compliant
- IP Rating: IP20
- Efficiency: Up to 80%
Physical Design & Installation
The PSD60-24 features a durable metal enclosure with an integrated junction box, allowing for direct hardwire connections. The design includes knockouts for easy conduit access, making it ideal for mounting in cabinets, utility rooms, or behind architectural features. Cooling is achieved through natural air convection.
Dimming & Controls
This driver supports Phase and TRIAC dimming protocols, providing a smooth dimming range from 20% to 100%. To ensure optimal performance and prevent flickering, a minimum load of 40% (24W) is recommended. It is compatible with popular dimming systems including Lutron Diva, Maestro, and Leviton Decora series.
Performance & Build
Engineered for longevity, this unit includes comprehensive protection against short circuits and over-voltage. It is Class 2 rated for safety and ETL compliant, ensuring it meets rigorous electrical standards. The IP20 rating makes it suitable for damp location environments where moisture may be present but direct water contact is avoided.
Typical Applications
- LED Tape Lighting
- Under Cabinet Puck Lights
- Linear LED Lightbars
- Architectural Accent Lighting
Specifications
Specifications
Dimensions
Documents
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
Does the PSD60-24 include a junction box?
Does the PSD60-24 include a junction box?
What is the dimming protocol for this GM Lighting driver?
What is the dimming protocol for this GM Lighting driver?
What is the minimum load requirement for the PSD60-24?
What is the minimum load requirement for the PSD60-24?
Is this LED driver Class 2 rated?
Is this LED driver Class 2 rated?
Can this driver be used in damp locations?
Can this driver be used in damp locations?
