GM Lighting PSD 15W 24VDC LED Driver Phase/Triac Dimming
In stock
About this item
About this item
- Output Voltage: 24VDC constant voltage with a 15W maximum power capacity.
- Dimming Protocol: Flicker-free Phase/Triac dimming from 20% to 100% range.
- Input Voltage: Standard 120VAC input suitable for residential and commercial applications.
- Enclosure Type: Features an integrated junction box for simplified hardwire installation.
- Safety Features: Class 2 rated with built-in short circuit and over-voltage protection.
We process payments securely and do not store credit card information.
Description
Description
GM Lighting PSD 15W LED Driver — 24VDC
The GM Lighting PSD15-24 is a 15W, 120V/24VDC, Phase/Triac, Class 2 LED Driver with Integrated Junction Box. This Constant Voltage power supply provides flicker-free dimming from 20% to 100% for LED tape and puck lights. It is designed for high efficiency and reliable performance in damp locations.
Key Features
- Power: 15W
- Output Voltage: 24VDC
- Input Voltage: 120VAC
- Dimming: Phase/Triac (20% - 100%)
- Minimum Load: 40% (6W)
- Dimensions: 8.375 in. L x 1.5 in. W x 1.625 in. H
- Enclosure Type: Integrated Junction Box
- IP Rating: IP20
- Class Rating: Class 2
- Certifications: ETL Compliant
Physical Design & Installation
The PSD series is engineered for ease of installation, featuring an Integrated Junction Box that allows for direct hardwire connections without the need for external enclosures. The compact design includes knockouts for streamlined wiring in tight spaces.
Dimming & Controls
This driver supports Phase/Triac dimming protocols, providing flicker-free performance from 20% to 100%. For optimal dimming results and stability, a Minimum Load of 40% (6W) is required, with a maximum recommended load of 85%.
Performance & Build
Built for reliability, the PSD15-24 includes comprehensive protection against short circuits and over-voltage. It is Class 2 compliant and features an IP20 rating, making it suitable for damp locations when properly installed.
Typical Applications
- Kitchen under-cabinet lighting
- Display case LED pucks
- Cove and accent tape lighting
