GM Lighting LTR-S SPEC LED Tape Light — 3500K & High Output

The GM Lighting LTR-S-HO-24V-8W-35K-100 is a high-output LED tape light offering a neutral white 3500K color temperature. This 98'6in. tape light operates at 24V DC and is dry rated, making it suitable for indoor applications. With a high CRI of 90+, it ensures excellent color rendering.

Key Features

• Voltage: 24V DC operation requires a compatible power supply.
• Wattage: Consumes 8 watts per foot for high brightness.
• Lumens per Foot: Delivers 1148 lumens per foot for bright illumination.
• LEDs per Foot: High-density placement for even light distribution.
• Maximum Run: 12 feet maximum run to prevent voltage drop.
• Cuttable Increments: Cuttable every 2 inches for custom installations.
• PCB Width: 10mm width compatible with standard channels.
• Beam Angle: 120-degree wide beam angle for broad coverage.
• IP Rating: IP20, suitable for dry locations.
• Certifications: ETL listed and Title 24 compliant.

Core Design & Construction

Featuring a 10mm PCB width, this tape light is designed for easy installation in standard aluminum channels. It includes a 3M adhesive backing for secure mounting and is protected by a durable coating suitable for dry environments.

LED Illumination & Performance

With 1148 lumens per foot and a CRI of 90+, this LED tape light provides high-quality illumination. The light engine is designed for high output, ensuring consistent and vibrant lighting.

Power, Wiring & Installation

This tape light requires a 24V DC power supply and is field cuttable every 2 inches. It supports dimming for customizable lighting levels and has a maximum continuous run of 12 feet to prevent voltage drop.

Where This Tape Works Best

• Cove lighting
• Under cabinet lighting
• Accent lighting
• Display case lighting

What's Included

• 98'6in. reel of LED tape light
• 48in. soldered lead
