GM Lighting LTR-S SPEC, 98'-6' LED Tape Light, 3000K, 200 Lumens/ft, 24V
In stock
About this item
About this item
- Voltage: Operates at 24V for efficient power consumption in architectural applications.
- Color Temperature: 3000K provides a warm white light ideal for ambient settings.
- Max Run: Supports a maximum continuous run of 32'-8' to minimize voltage drop.
- Cuttable: Field cuttable every 1' for precise length customization.
- PCB Width: 10mm width ensures compatibility with standard channels.
We process payments securely and do not store credit card information.
Description
Description
GM Lighting LTR-S SPEC LED Tape Light — 3000K & High CRI
The GM Lighting LTR-S-24V-2.5W-30K-100 is a high-performance LED tape light designed for architectural-grade applications. This 98'-6' tape light operates at 24V and is Dry Rated, making it ideal for indoor environments. With a 3000K color temperature, it delivers a warm and inviting ambiance.
Key Features
- Voltage: 24V DC ensures efficient power usage.
- Wattage: 2.5 watts per foot for energy-efficient lighting.
- Lumens: 200 lumens per foot for bright illumination.
- LED Density: 72 LEDs per foot for uniform light distribution.
- Max Run: 32'-8' on a single power feed to prevent voltage drop.
- Cuttable: Every 1' for custom installations.
- PCB Width: 10mm for compatibility with various channels.
- Beam Angle: 120° for wide light dispersion.
- IP Rating: Dry Rated for indoor use.
- Certifications: UL Listed, Title 24 compliant.
Core Design & Construction
The tape light features a 10mm PCB width, ensuring compatibility with standard aluminum channels. It includes a 3M adhesive backing for easy installation and is designed for dry indoor environments.
LED Illumination & Performance
With a brightness of 200 lumens per foot and a high CRI of 95+, this tape light provides excellent color rendering and consistent illumination. The light engine is designed for warm white output at 3000K.
Power, Wiring & Installation
This 24V tape light requires a compatible driver (sold separately). It is field cuttable every 1' and supports a maximum continuous run of 32'-8'. The tape is dimmable for adjustable lighting levels.
Where This Tape Works Best
- Cove lighting
- Under cabinet lighting
- Accent lighting
- Display case lighting
What's Included
- 98'-6' reel of LED tape light
- (10) ESTW-60 Sure-Tite connectors
Specifications
Specifications
Dimensions
Documents
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the maximum run length for the LTR-S-24V-2.5W-30K-100?
What is the maximum run length for the LTR-S-24V-2.5W-30K-100?
How often can the LTR-S-24V-2.5W-30K-100 be cut?
How often can the LTR-S-24V-2.5W-30K-100 be cut?
What voltage is required for the LTR-S-24V-2.5W-30K-100?
What voltage is required for the LTR-S-24V-2.5W-30K-100?
Is the LTR-S-24V-2.5W-30K-100 compatible with standard channels?
Is the LTR-S-24V-2.5W-30K-100 compatible with standard channels?
Does the LTR-S-24V-2.5W-30K-100 come with a power supply?
Does the LTR-S-24V-2.5W-30K-100 come with a power supply?
