GLT Dusk to Dawn LED Area Light — 80W Selectable — 3000K/4000K/5000K — Wall Mount — Silver Gray

The GLT BGR-ALO2-MVOLT-PE-DNA brings dusk-to-dawn lighting to building entryways, pathways, yards, and loading docks with an included photocell and a direct wall-mount design. This Silver Gray LED area light is UL/cUL wet-location listed and supports wall mounting only. Its 80W maximum setting delivers up to 12,000 lm at 4000K, with 64W, 48W, and 32W settings available when lower output is preferred. Select 3000K, 4000K, or 5000K to choose the light's color temperature. The fixture operates on 120–277V and replaces up to 250W metal halide.

Key Features

• Dusk-to-Dawn Control: The included photocell provides dusk-to-dawn operation for exterior area lighting.
• Direct Wall Mounting: Installs directly on a wall surface for building-mounted illumination; this configuration supports wall mounting only.
• Outdoor Location Listing: UL/cUL wet-location listing supports installation in outdoor wet locations.
• Selectable Wattage: Choose the 80W setting for maximum output, or select 64W, 48W, or 32W for lower power and light output.
• Maximum Light Output: Delivers up to 12,000 lm at 80W and 4000K; lumen output varies with the selected wattage and color temperature.
• Metal Halide Replacement: Provides an LED replacement for metal halide lighting up to 250W.
• Selectable Color Temperature: Choose 3000K, 4000K, or 5000K within the same fixture.
• Input Voltage: Accepts 120–277V input power for the electrical connection.
• Operating Temperature: Supports operation from −40°F (−40°C) to 104°F (40°C).
• Housing & Finish: Combines a die-cast aluminum housing with a Silver Gray polyester powder-coat finish.
• Peak Efficacy: Reaches 159 lm/W at 32W and 4000K; this is distinct from the maximum-output setting.
• Color Rendering: Provides CRI 70 for the fixture's area-lighting output.
• LED Lifespan: Estimated LED lifespan exceeds 50,000 hours.
• Warranty Coverage: Includes a five-year warranty for the fixture.

Performance & Light Output

The 80W setting provides the highest light output. The 64W, 48W, and 32W settings reduce output in steps, while the three CCT choices also affect the lumen and efficacy values. Compare the wattage and color-temperature combination together rather than treating the maximum lumen figure as the output at every setting.

At 80W: 11,200 lm (3000K / 140 lm/W); 12,000 lm (4000K / 150 lm/W); and 11,600 lm (5000K / 145 lm/W).

At 64W: 9,200 lm (3000K / 144 lm/W); 9,800 lm (4000K / 153 lm/W); and 9,600 lm (5000K / 150 lm/W).

At 48W: 7,000 lm (3000K / 146 lm/W); 7,500 lm (4000K / 156 lm/W); and 7,400 lm (5000K / 154 lm/W).

At 32W: 4,800 lm (3000K / 150 lm/W); 5,100 lm (4000K / 159 lm/W); and 5,000 lm (5000K / 156 lm/W).

Color rendering is CRI 70. Estimated LED lifespan exceeds 50,000 hours.

Dusk-to-Dawn Control

A photocell is included with the fixture to provide dusk-to-dawn control. This control function is separate from the wattage and color-temperature selections: the photocell controls dusk-to-dawn operation, while the selectable settings determine the light output and color temperature.

Electrical

The fixture operates on 120–277V with selectable power settings of 80/64/48/32W. Electrical performance includes a power factor of ≥0.9 and total harmonic distortion of ≤20%.

At the 80W setting, operating current varies with input voltage as follows:

Construction

Housing & Finish: The fixture uses a die-cast aluminum housing finished in Silver Gray polyester powder coat.

Outdoor Suitability: UL/cUL wet-location listing supports exterior installations exposed to wet conditions. The operating temperature range is −40°F (−40°C) to 104°F (40°C).

Installation & Mounting

Wall-Mount Configuration: This fixture mounts directly to a wall surface, placing the light at the building rather than on a separate pole. This configuration supports wall mounting only.

Electrical Connection: The fixture accepts 120–277V input power. Use the operating-current values above when reviewing the fixture's electrical specifications.

Certifications & Warranty

• UL/cUL Wet Location: Listed for wet-location installations.
• Five-Year Warranty: The fixture carries a five-year warranty.

Typical Applications

• Building Entryways: Direct wall mounting places exterior lighting at the building entrance.
• Pathways: The included photocell provides dusk-to-dawn control for pathway illumination.
• Yards: Four wattage settings provide a choice of light-output levels for yard lighting.
• Loading Docks: Wet-location listing supports lighting at outdoor loading-dock areas.

What's Included

• GLT BGR-ALO2-MVOLT-PE-DNA LED Area Light in Silver Gray.
• Dusk-to-dawn photocell.
