GLT ALG Shoebox Area Light — 150W, 5000K, 120–277V

The GLT ALG-150W-UV-T5-50K-D10 is a high-performance LED shoebox area light delivering 21,600 lumens at a dedicated 150W output and 5000K color temperature. Operating on a 120–277V universal driver, this fixture features a clean, slim profile design and precision Type V distribution. Built with an IP65 Wet Location rating and DLC Premium certification, it is engineered for exceptional durability in parking lots, auto dealerships, and outdoor retail shopping centers.

Key Features

• Wattage: 150W
• CCT: 5000K
• Delivered Lumens: 21,600 lumens (144 LPW)
• Voltage: 120–277V input
• Dimming: 0–10V continuous dimming (10-100%)
• Optics: Type V distribution
• CRI: 70
• HID Equivalent: Replaces up to 400W Metal Halide
• Environmental Ratings: IP65 rated for damp and wet locations
• Certifications: cETL, ETL, DLC Premium
• Estimated Life: 50,000 hours (L70)

Typical Applications

• Commercial parking lots
• Auto dealerships
• University and corporate campuses
• Recreational spaces
• Outdoor retail shopping centers

Performance & Light Output

This slim-profile area light produces 21,600 lumens at a crisp 5000K color temperature, achieving an excellent efficacy of 144 lumens per watt. The ultra-efficient LED optics generate a Type V symmetrical distribution pattern, which is ideal for broad central illumination in large open areas. The high-efficacy LED chips deliver a color rendering index (CRI) of 70 and maintain a highly prolonged L70 rated life of 50,000 hours.

Electrical & Controls

This shoebox light operates on an integral high-performance UL qualified LED driver utilizing a universal 120–277V AC power supply. The electrical system is equipped with standard continuous 0–10V dimming capabilities, allowing for lighting adjustments from 10% to 100% to maximize energy savings. For additional defense against power anomalies, optional 10KV surge protectors (sold separately) can be integrated into the system.

Construction & Durability

Engineered to withstand extreme climate changes, the luminaire features a heavy-duty ADC12 die-cast aluminum housing finished in a rust and corrosion-proof bronze polyester powder coat. The housing is fully sealed to be completely dirt and bug proof. The fixture incorporates a UV-free polycarbonate lens and carries an IP65 rating, ensuring reliable operation in damp and wet locations across ambient temperatures ranging from -20°C to 40°C.

Installation & Mounting

The ALG series features a revolutionary universal mounting design that allows for incredible site flexibility. The fixture requires a compatible mounting accessory (ordered separately) to complete the installation. Contractors can choose from flexible adapters designed for round or square pole mounting, slipfitters, or trunnion mounts depending on the exact application needs.

What's Included

• LED Shoebox Area Light (Bronze)
• Note: Mounting hardware sold separately.
