Odyn Custom Brushed Nickel Ceiling Fan Motor & Light, Blades Sold Separately
Available in stock (334)
About this item
About this item
- Airflow (CFM): 9193 at high speed
- Motor Type: DC Motor
- Environment Rating: Wet Location
- Controls: Includes Wi-Fi receiver and remote control
- Blade Span: 72'' with 12° blade pitch
We process payments securely and do not store credit card information.
Description
Description
Fanimation Odyn 72'' Ceiling Fan — Brushed Nickel
The Fanimation MAD8152BNW is a 72'' ceiling fan featuring a sleek Brushed Nickel finish. It includes a powerful DC motor and is rated for wet locations, making it ideal for large spaces over 400 sq ft. This fan comes with a set of nine blades sold separately, allowing customization of blade span options.
Key Features
- Motor: DC135 sensorless DC motor for optimal performance
- Light Kit: 18-watt CCT LED with selectable color temperatures (3000K, 4000K, 5000K)
- Airflow: 9193 CFM at high speed
- Efficiency: 321 CFM/W at high speed
- Control: Wi-Fi receiver and TR305 remote control included
- Blade Options: 56'', 64'', and 72'' blade sweep options
- Sloped Ceiling: Compatible up to 27°, optional kits available for greater angles
- Downrod: Includes 12'' downrod, optional lengths available
Construction & Design
Features a durable all-weather composite blade material with a 12° blade pitch, designed for both style and performance in wet locations.
Smart & Control Features
Includes a Wi-Fi receiver and TR305 remote control with 16 fan speeds, reverse function, and CCT selection. Compatible with fanSync WiFi APP for enhanced control.
Electrical & Installation
Requires a 120V grounded electrical supply. Compatible with sloped ceilings up to 27° with included downrod, additional kits available for steeper angles.
Light Output & Performance
Delivers 1600 lumens with a high CRI of 90%. Offers selectable CCT for customizable lighting ambiance.
What's Included
- Wi-Fi receiver
- TR305 remote control
- 12'' downrod
- Installation instructions
Specifications
Specifications
Dimensions
Documents
Style & Materials
Characteristics & Features
Fan Information
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
How high should a ceiling fan be from the floor?
How high should a ceiling fan be from the floor?
For residential fans, safety codes require a minimum clearance of 7.5 feet under the blades. If you are installing an industrial-rated fan, a minimum of 10 feet is required. For ceilings higher than 12 feet, hang your fan at least one-third the distance to the floor while maintaining that 7.5-foot minimum clearance. For optimal performance, a height of 9–10 feet is ideal.
How many blades are best for a ceiling fan?
How many blades are best for a ceiling fan?
Airflow is determined by a combination of factors including motor size, blade pitch, and blade materials. Instead of counting blades, compare fans using their standardized Airflow (CFM) and Airflow Efficiency (CFM per Watt) ratings. A higher CFM means more air is moved, while higher efficiency means more air movement per watt of electricity used.
What is a "Hugger" or Low Profile fan?
What is a "Hugger" or Low Profile fan?
A hugger fan is designed to be installed flush against the ceiling without a downrod. These should be used exclusively in rooms with a ceiling height of 8 feet or less to maximize headroom while maintaining safe clearance.
Can I put a regular ceiling fan outside?
Can I put a regular ceiling fan outside?
No. You must use an outdoor-rated fixture. Use Damp Rated fans for covered areas like screened porches, and Wet Rated fans for exposed structures like pergolas where the fan will be in direct contact with rain or snow.
Can I use a dimmer switch with my ceiling fan?
Can I use a dimmer switch with my ceiling fan?
Do not use a standard wall dimmer for the fan motor, as it can cause humming or permanent motor damage. You must use a specialized Fan Speed Control or the remote control specifically designed for that model.
