Fanimation Spitfire MA6721B 60 in AC Ceiling Fan Motor

Create a custom propeller-style fan with the Spitfire 60 in AC motor platform and a separately selected wood blade finish. The 188 × 25 mm AC motor delivers 4,908 CFM high-speed airflow, with a TR500 remote included. Damp rated for indoor and covered outdoor settings protected from direct rain. Motor unit only: required B6720 blades and the optional matching LED light kit are sold separately.

Key Features

• Completed sweep: 60 in with the required separately purchased B6720 three-blade wood set.
• Motor: 188 × 25 mm AC motor with three speeds.
• High airflow: 4,908 CFM.
• Medium airflow: 3,273 CFM.
• Low airflow: 1,693 CFM.
• Location: Damp rated for indoor and sheltered outdoor use.
• Control: TR500 hand-held remote included; WFR50 WiFi receiver optional.
• Downrod: 4.5 in length with 1 in diameter included.

Smart & Control Features

The included TR500 remote provides fan speed and on/off control. Lighting control requires an optional compatible light kit. WiFi is not included; the optional WFR50 receiver adds fanSync WiFi connectivity. Optional wall controls include WC2WH and WR501WH, sold separately.

Construction & Design

The 60 in measurement describes the completed blade sweep, not the 7.09 in motor housing width. Purchase a compatible B6720 wood blade set independently to create the three-blade propeller profile. Finish-specific model and accessory pairings include:

• Black: MA6721BBL motor; LK6721BBL light kit and CCK6721BL close-to-ceiling kit.
• Brushed Nickel: MA6721BBN motor; LK6721BBN light kit and CCK6721BN close-to-ceiling kit.
• Brushed Brass: Brushed Satin Brass MA6721BBS motor; LK6721BBS light kit and CCK6721BS close-to-ceiling kit.
• Dark Bronze: MA6721BDZ motor; LK6721BDZ light kit and CCK6721DZ close-to-ceiling kit.
• Galvanized: MA6721BGZ motor; LK6721BGZ light kit and CCK6721GZ close-to-ceiling kit.
• Matte Greige: MA6721BGR motor; LK6721BGR light kit and CCK6721GR close-to-ceiling kit.

Light Output & Performance

No light kit is included. The optional matching LK6721B family LED kits provide 924 lumens from 18W at 3000K with 90 CRI, and include Fresnel and frosted shades. Select the kit matched to the motor finish. With the required B6720 blades, airflow is 4,908 CFM high, 3,273 CFM medium and 1,693 CFM low.

Electrical & Installation

A 4.5 in downrod with 1 in diameter and mounting hardware are included. Standard downrod mounting supports slopes up to 19°. For steeper slopes up to 42°, add the optional SCK1-52 slope ceiling kit. Matching CCK6721 close-to-ceiling kits are sold separately. The optional DR1-CP** coupler joins downrods for runs beyond 72 in; ** identifies the finish suffix. Maintain at least 7 ft floor-to-blade clearance and keep damp-rated installations protected from direct rain.

Suggested Downrod by Ceiling Height

A 4.5 in downrod is included. Longer downrods and close-to-ceiling kits are sold separately. Select final hardware for the ceiling slope and completed fan dimensions, preserving at least 7 ft from floor to blades.

• Below 9 ft ceiling → matching CCK6721 close-to-ceiling kit, only where required clearances can be maintained
• 9 ft ceiling → shorter than 12 in; 4.5 in downrod included
• 10 ft ceiling → 12–18 in downrod
• 11 ft ceiling → 18–24 in downrod
• 12 ft ceiling → 24–36 in downrod
• 13 ft ceiling → 36–48 in downrod
• 14 ft ceiling → 48–60 in downrod
• 15 ft or higher → 72 in downrod or coupled downrods as required

What's Included

• Spitfire MA6721B AC motor unit for the 60 in configuration in the selected finish
• TR500 hand-held remote
• 4.5 in downrod with 1 in diameter
• Mounting hardware

B6720 blades and the optional matching LK6721B LED light kit are not included and must be purchased separately.
