VALENT MINI, 16 ft. LED Tape Light, 4000K, 750 Lumens/ft, 24V
In stock
About this item
About this item
- Color Temperature: Provides a crisp 4000K color temperature for versatile lighting applications.
- Voltage: Operates at 24V, ensuring efficient power consumption and compatibility with standard drivers.
- Max Run: Supports a maximum run of 22 ft, ideal for extended linear installations.
- Cuttable Increments: Field cuttable every 1.09 in. for precise length customization.
- IP Rating: Rated IP20, suitable for indoor and damp locations.
We process payments securely and do not store credit card information.
Description
Description
VALENT MINI LED Tape Light — 4000K & High Density
The VALENT MINI DI-24V-VL10MN5-40-016 is a high-density LED tape light designed for seamless, dot-free illumination. This 16 ft tape light operates at 24V and is IP20 rated, making it suitable for indoor and damp locations.
Key Features
- Voltage: 24V DC for efficient power usage.
- Wattage: 4.5W/ft for optimal brightness.
- Lumens: 750 lumens per foot for bright illumination.
- LED Density: 88 LEDs per foot for high-density lighting.
- Max Run: 22 ft maximum run length.
- Cuttable: Cuttable every 1.09 in. for custom lengths.
- Width: 10mm PCB width for compatibility with standard channels.
- Beam Angle: 120° for wide light distribution.
- Certifications: UL Listed, RoHS Compliant, Title 24.
Core Design & Construction
The tape light features a slim 10mm width, allowing for installation in tight spaces. It includes a durable adhesive backing for secure mounting and is compatible with various aluminum channels for enhanced diffusion.
LED Illumination & Performance
Delivering 750 lumens per foot with a 90+ CRI, this tape light ensures vibrant and accurate color rendering. The high-density LED placement provides a seamless, dot-free lighting effect.
Power, Wiring & Installation
Requires a 24V driver for operation. The tape light is dimmable and can be cut every 1.09 inches, allowing for precise customization. Ensure a maximum run of 22 ft to prevent voltage drop.
Where This Tape Works Best
- Cove lighting
- Under cabinet lighting
- Accent lighting
- Display case lighting
What's Included
- 16 ft spool of LED tape light
- 36 in. white bare lead wire
Specifications
Specifications
Dimensions
Documents
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the maximum run length for the VALENT MINI tape light?
What is the maximum run length for the VALENT MINI tape light?
How often can the VALENT MINI tape light be cut?
How often can the VALENT MINI tape light be cut?
What voltage is required for the VALENT MINI tape light?
What voltage is required for the VALENT MINI tape light?
Is the VALENT MINI tape light dimmable?
Is the VALENT MINI tape light dimmable?
What channel sizes are compatible with the VALENT MINI tape light?
What channel sizes are compatible with the VALENT MINI tape light?
