BLAZE, 100 ft., LED Tape Light, 5000K, 237 Lumens/ft, 24V
Available in stock (200)
About this item
About this item
- Color Temperature: Provides a crisp 5000K light, ideal for task lighting.
- Voltage: Operates at 24V DC, ensuring efficient energy use.
- Max Run: Supports up to 22 ft. continuous runs to minimize voltage drop.
- Cuttable: Field cuttable every 1.96 in. for custom lengths.
- Environment: Suitable for indoor damp locations with IP20 rating.
We process payments securely and do not store credit card information.
Description
Description
BLAZE LED Tape Light — 5000K & High CRI
The BLAZE DI-24V-BLBSC3-50-100 is a high-performance LED tape light offering a crisp 5000K color temperature. This 100 ft. spool is designed for 24V systems and is suitable for indoor damp environments.
Key Features
- Voltage: 24V DC operation for efficient energy use.
- Wattage: 4.5W per foot for balanced power consumption.
- Lumens: 237 lumens per foot for bright illumination.
- LED Density: 36 LEDs per foot for uniform light distribution.
- Max Run: Up to 22 ft. continuous run to minimize voltage drop.
- Cuttable: Field cuttable every 1.96 in. for custom lengths.
- PCB Width: 8mm, compatible with standard channels.
- Beam Angle: 120 degrees for wide light distribution.
- IP Rating: IP20, suitable for indoor damp locations.
- Certifications: UL Listed, RoHS compliant, Title 24.
Core Design & Construction
The tape light features an 8mm PCB width, ensuring compatibility with most aluminum channels. It includes a durable 3M adhesive backing for secure installation in various environments.
LED Illumination & Performance
With 237 lumens per foot and a 90+ CRI, this LED tape light delivers high-quality illumination with excellent color rendering, ideal for task and accent lighting.
Power, Wiring & Installation
Requires a 24V DC power supply. The tape is field cuttable every 1.96 in., allowing for precise customization. Supports dimming for adjustable lighting levels.
Where This Tape Works Best
- Under cabinet lighting
- Cove lighting
- Accent lighting
- Display case lighting
What's Included
- 100 ft. spool of LED tape light
- 36 in. bare lead wire
- 2x White Tape-to-Wire Terminal Blocks
Specifications
Specifications
Dimensions
Documents
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the maximum run length for the BLAZE DI-24V-BLBSC3-50-100?
What is the maximum run length for the BLAZE DI-24V-BLBSC3-50-100?
How often can the tape be cut?
How often can the tape be cut?
What voltage is required for this LED tape light?
What voltage is required for this LED tape light?
Is this tape light suitable for outdoor use?
Is this tape light suitable for outdoor use?
What type of adhesive backing does it have?
What type of adhesive backing does it have?
