Diode LED BLAZE, 16 ft, LED Tape Light, 2700K, 338 Lumens/ft, 24V
Available in stock (199)
About this item
About this item
- Color Temperature: Provides a warm 2700K light, ideal for cozy and inviting environments.
- Voltage: Operates at 24V, ensuring compatibility with low-voltage systems.
- Max Run: Capable of running up to 22 ft continuously, minimizing voltage drop.
- Cuttable Increments: Field cuttable every 1.96 in., allowing for precise length customization.
- CRI: Features a high CRI of 90+, ensuring accurate color rendering.
We process payments securely and do not store credit card information.
Description
Description
Diode LED BLAZE LED Tape Light — 2700K & High CRI
The Diode LED DI-24V-BLBSC3-27-016 is a high-performance LED tape light designed for versatile lighting applications. This 16-foot tape light offers a warm 2700K color temperature and operates at 24V, making it suitable for damp locations.
Key Features
- Voltage: Operates at 24V for low-voltage applications.
- Wattage: Consumes 4.5W per foot, ensuring energy efficiency.
- Lumens: Delivers 338 lumens per foot for bright illumination.
- LEDs: Features 36 LEDs per foot for consistent light output.
- Max Run: Supports a maximum run length of 55 ft.
- Cuttable: Can be cut every 1.96 in. for custom installations.
- PCB Width: Measures 0.31 in. wide, compatible with standard channels.
- Beam Angle: Provides a 120-degree beam angle for wide light distribution.
- IP Rating: Rated for indoor/damp locations (IP20).
- Certifications: UL Listed, RoHS Compliant, and Title 24 compliant.
Core Design & Construction
The tape light features a 0.31 in. wide PCB, ensuring compatibility with most aluminum channels. It includes a durable adhesive backing for easy installation and is rated for damp environments.
LED Illumination & Performance
With 338 lumens per foot and a CRI of 90+, this tape light provides excellent color rendering and brightness, ideal for accent and task lighting.
Power, Wiring & Installation
Requires a 24V driver for operation. The tape light is field cuttable every 1.96 in., allowing for precise customization. It supports dimming for adjustable light levels.
Where This Tape Works Best
- Cove lighting
- Under cabinet lighting
- Accent lighting
- Display case lighting
What's Included
- 16 ft spool of LED tape light
- 36 in. bare lead wire
- 2x White Tape-to-Wire Terminal Blocks
Specifications
Specifications
Dimensions
Documents
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the maximum run length for the DI-24V-BLBSC3-27-016 tape light?
What is the maximum run length for the DI-24V-BLBSC3-27-016 tape light?
How often can the tape light be cut?
How often can the tape light be cut?
What voltage is required for the DI-24V-BLBSC3-27-016 tape light?
What voltage is required for the DI-24V-BLBSC3-27-016 tape light?
Is the DI-24V-BLBSC3-27-016 tape light dimmable?
Is the DI-24V-BLBSC3-27-016 tape light dimmable?
What is the width of the PCB for channel compatibility?
What is the width of the PCB for channel compatibility?
