Diode LED tape light strip showing rows of 6000K LED chips on clear PCB
4000K LED tape light strip, 16 ft length, 24V damp-rated, visible LED chip row
LED tape light strip for under-cabinet lighting, warm white glow
Curved LED tape light strip with certification icons and 24V/VDC marking
LED tape light accessories diagram set with mounting and connector options
LED tape light strip close-up with small warm-white LED chips and circuit marks
LED tape light strip, 8mm wide, with evenly spaced surface-mounted LEDs
Warm-white LED tape lighting for interior accent under surfaces
Warm-white LED tape lighting used for room accent along shelves and wall
Diode LED tape light strip showing rows of 6000K LED chips on clear PCB
4000K LED tape light strip, 16 ft length, 24V damp-rated, visible LED chip row
LED tape light strip for under-cabinet lighting, warm white glow
Curved LED tape light strip with certification icons and 24V/VDC marking
LED tape light accessories diagram set with mounting and connector options
LED tape light strip close-up with small warm-white LED chips and circuit marks
LED tape light strip, 8mm wide, with evenly spaced surface-mounted LEDs
Warm-white LED tape lighting for interior accent under surfaces
Warm-white LED tape lighting used for room accent along shelves and wall

Diode LED BLAZE, 16 ft, LED Tape Light, 4000K, 260 Lm/ft, 24V

Vendor: Diode LED

SKU: DI-24V-BLBSC2-40-016

NewQuick Ship
$129.95
$0.00
Shipping calculated at checkout.
Voltage: 24V
Length: 16ft
Light color: 4000K Cool White

Available in stock (100)

Must be ordered in quantities of .

About this item
  • Color Temperature: Provides a neutral white light at 4000K, ideal for task lighting.
  • Voltage: Operates at 24VDC, ensuring efficient energy consumption.
  • Max Run: Capable of a maximum continuous run of 40 ft, suitable for extensive installations.
  • Cuttable Increments: Can be cut every 1.96 in. for customized lengths.
  • IP Rating: Rated for indoor/damp locations with IP20, not suitable for wet environments.
View More Details

Description

Diode LED BLAZE LED Tape Light — 4000K & High CRI

The Diode LED BLAZE DI-24V-BLBSC2-40-016 is a high-performance LED tape light offering a neutral white light at 4000K. This tape light spans 16 ft and operates on 24VDC, making it ideal for indoor and damp locations.

Key Features

  • Voltage: 24VDC for efficient operation.
  • Wattage: Consumes 2.93W/ft.
  • Lumens: Delivers 260 Lm/ft for bright illumination.
  • LEDs per Foot: 36 LEDs/ft for consistent light output.
  • Max Run: Supports up to 40 ft continuous run.
  • Cuttable: Field cuttable every 1.96 in. for custom lengths.
  • PCB Width: 0.31 in. for compatibility with standard channels.
  • Beam Angle: 120° for wide light distribution.
  • IP Rating: IP20 for indoor/damp applications.
  • Certifications: UL Listed, Title 24 compliant.

Core Design & Construction

Featuring a PCB width of 0.31 in., this tape light is compatible with various aluminum channels. It includes a durable adhesive backing for easy installation and is designed for indoor/damp environments.

LED Illumination & Performance

With 260 Lm/ft and a high CRI of 90+, this LED tape light ensures excellent color rendering and brightness, utilizing standard SMD technology.

Power, Wiring & Installation

Requires a 24V driver (sold separately). The tape light is field cuttable every 1.96 in. and supports dimming for versatile lighting control.

Where This Tape Works Best

  • Cove lighting
  • Under cabinet lighting
  • Accent lighting
  • Display case lighting

What's Included

  • 16 ft spool of LED tape light
  • 36 in. bare lead wire
  • 2x White Tape-to-Wire Terminal Blocks

Specifications

Dimensions

Length/Depth
192 in
Width/Diameter
0.31 in
Height
0.1 in
Weight
2 lb

Documents

Characteristics & Features

Lamp Color
4000K
Color Rendering
90 CRI

Electrical Information

Voltage
24V

Item Details

MPN
DI-24V-BLBSC2-40-016
Brand
Diode LED
Family
BLAZE
UPC
848333019982

Warranty & Certifications

Product Warranty
10-year limited warranty
Lamp Life
50,000 Hours
Product Rating
Damp Rated

Shipping & Returns

Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.

Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.

See Full Shipping Policy | See Full Return Policy

Frequently Asked Questions

What is the maximum run length for the DI-24V-BLBSC2-40-016?
The maximum run length is 40 ft. Exceeding this may cause voltage drop.

How often can the tape light be cut?
The tape light can be cut every 1.96 inches for custom lengths.

What voltage is required for this LED tape light?
This LED tape light requires a 24VDC power supply.

Is this tape light suitable for outdoor use?
No, it is rated IP20 for indoor/damp locations only.

What type of channels are compatible with this tape light?
Channels with a width of at least 0.31 inches are compatible.
