BLAZE, 16ft LED Tape Light, 3500K, 249 Lm/ft, 24V
Available in stock (100)
About this item
About this item
- Color Temperature: Provides a balanced 3500K light, ideal for versatile applications.
- Voltage: Operates at 24VDC, ensuring efficient power consumption.
- Max Run: Supports up to 40 ft. continuous run, minimizing voltage drop.
- Cuttable Increments: Field cuttable every 1.96 in. for precise installations.
- IP Rating: Rated IP20 for indoor and damp locations.
We process payments securely and do not store credit card information.
Description
Description
BLAZE LED Tape Light — 3500K & High CRI
The BLAZE DI-24V-BLBSC2-35-016 is a 16ft LED tape light offering a balanced 3500K color temperature with a high 90+ CRI. This tape light operates at 24VDC and is suitable for indoor and damp locations with an IP20 rating.
Key Features
- Voltage: 24VDC for efficient operation.
- Wattage: 2.93W/ft. for energy-efficient lighting.
- Lumens: 249 Lm/ft. for bright illumination.
- LEDs per Foot: 36 LEDs/ft. for consistent light output.
- Max Run: 40 ft. continuous run to minimize voltage drop.
- Cuttable: Every 1.96 in. for custom lengths.
- PCB Width: 0.31 in. for compatibility with most channels.
- Beam Angle: 120° for wide light distribution.
- Certifications: UL Listed, Title 24 compliant.
Core Design & Construction
The tape light features a 0.31 in. wide PCB, suitable for most aluminum channels, and includes a durable 3M adhesive backing for easy installation in dry and damp environments.
LED Illumination & Performance
With 249 Lm/ft. and a high CRI of 90+, this LED tape light ensures vibrant and accurate color rendering, using standard SMD technology.
Power, Wiring & Installation
Requires a 24V driver (sold separately). The tape is field-cuttable every 1.96 in. and supports up to 40 ft. continuous runs. It is dimmable for customizable lighting.
Where This Tape Works Best
- Cove lighting
- Under cabinet lighting
- Accent lighting
- Display case lighting
What's Included
- 16 ft. spool of LED tape light
- 36 in. bare lead wire with strain relief
- 2x White Tape-to-Wire Terminal Blocks
Specifications
Specifications
Dimensions
Documents
Characteristics & Features
Electrical Information
Item Details
Warranty & Certifications
Shipping & Returns
Shipping: Enjoy free standard shipping on most orders over $99. Exclusions apply for oversized & commercial items. We ship to the contiguous 48 United States.
Returns: We offer a 60-day return window for most items. Products must be in their original, unused condition with all packaging. Exclusions: Special orders, clearance, and custom items.
Frequently Asked Questions
What is the maximum run length for the BLAZE DI-24V-BLBSC2-35-016 tape light?
What is the maximum run length for the BLAZE DI-24V-BLBSC2-35-016 tape light?
How often can the BLAZE tape light be cut?
How often can the BLAZE tape light be cut?
What voltage is required for the BLAZE DI-24V-BLBSC2-35-016 tape light?
What voltage is required for the BLAZE DI-24V-BLBSC2-35-016 tape light?
Is the BLAZE tape light compatible with aluminum channels?
Is the BLAZE tape light compatible with aluminum channels?
What is the CRI of the BLAZE DI-24V-BLBSC2-35-016 tape light?
What is the CRI of the BLAZE DI-24V-BLBSC2-35-016 tape light?
